13
KNIFE TRANSFER TOOL
STORAGE
1. The knife transfer tool (A) Fig. 20, supplied with your
planer, can easily be stored underneath the outfeed
table extension (B) when not being used. A Velcro strip
(C) is provided on the tool and underneath the table for
this purpose.
2. Figure 21 illustrates the knife transfer tool (A) stored
underneath the outfeed table extension.
Fig. 20
B
C
A
C
Fig. 21
WRENCH STORAGE
The wrench (A) Fig. 21, can be stored in hole (B) located
on the right rear side of the machine as shown.
A
B
