Chapter 11 Summary of Parameter SettingsCFP2000 Series
11-16
05 Motor Parameters
Pr.
Explanation
Settings
Factory
Setting
05-00
Motor Auto Tuning
0: No function
1: Rolling test for induction motor(IM) (Rs, Rr, Lm, Lx,
no-load current)
2: Static test for induction motor(IM)
5: Dynamic test for PM(SPM) motor
13: Stacic test for PM(IPM) motor
0
05-01
Full-load Current of Induction
Motor 1(A)
10~120% of drive’s rated current
#.##

05-02
Rated Power of Induction Motor
1(kW)
0~655.35kW
#.##

05-03
Rated Speed of Induction Motor
1 (rpm)
0~65535
1710 (60Hz 4poles) ; 1410(50Hz 4 poles)
1710
05-04
Pole Number of Induction Motor
1
2~20
4
05-05
No-load Current of Induction
Motor 1 (A)
0~ Pr.05-01 factory setting
#.##
05-06
Stator Resistance (Rs) of
Induction Motor 1
0.000~65.535
0.000
05-07
Rotor Resistance (Rr) of
Induction Motor 1
0.000~65.535
0.000
05-08
Magnetizing Inductance (Lm) of
Induction Motor 1
0~6553.5mH
0.0
05-09
Stator Inductance (Lx) of
Induction Motor 1
0~6553.5mH
0.0
05-10
~
05-12
Reserved
05-13
Full-load Current of Induction
Motor 2 (A)
10~120%
#.##

05-14
Rated Power of Induction Motor
2 (kW)
0~655.35kW
#.##

05-15
Rated Speed of Induction Motor
2 (rpm)
0~65535
1710(60Hz 4 poles) ; 1410(50Hz 4 poles)
1710
05-16
Pole Number of Induction Motor
2
2~20
4
05-17
No-load Current of Induction
Motor 2 (A)
0~ Pr.05-01 factory setting
#.##
05-18
Stator Resistance (Rs) of
Induction Motor 2
0.000~65.535
0.000
05-19
Rotor Resistance (Rr) of
Induction Motor 2
0.000~65.535
0.000
05-20
Magnetizing Inductance (Lm) of
Induction Motor 2
0~6553.5mH
0.0
05-21
Stator Inductance (Lx) of
Induction Motor 2
0~6553.5mH
0.0
05-22
Induction Motor 1/ 2 Selection
1: motor 1
2: motor 2
1

05-23
Frequency for
Y-connection/△ -connection
Switch of Induction Motor
0.00~599.00Hz
60.00
05-24
Y-connection/△ -connection
Switch of Induction Motor
0: Disable
1: Enable
0
05-25
Delay Time for
Y-connection/△ -connection
Switch of Induction Motor
0.000~60.000 seconds
0.200
05-26
Reserved
