Chapter 11 Summary of Parameter SettingsCFP2000 Series
11-18
06 Protection Parameters
Pr.
Explanation
Settings
Factory
Setting

06-00
Low Voltage Level
300.0~440.0Vdc
360.0

06-01
Over-voltage Stall Prevention
700.0~900.0Vdc
760.0

06-02
Selection for Over-voltage Stall
Prevention
0: Traditional over-voltage stall prevention
1: Smart over-voltage prevention
0

06-03
Over-current Stall Prevention
during Acceleration
Normal Load: 0~160%(100%: drive’s rated current)
Light Load: 0~130%(100%: drive’s rated current)
120

06-04
Over-current Stall Prevention
during Operation
Normal Load: 0~160%(100%: drive’s rated current)
Light Load: 0~130%(100%: drive’s rated current)
120

06-05
Accel. /Decel. Time Selection of
Stall Prevention at Constant
Speed
0: by current accel/decel time
1: by the 1st accel/decel time
2: by the 2nd accel/decel time
3: by the 3rd accel/decel time
4: by the 4th accel/decel time
5: by auto accel/decel
0

06-06
Over-torque Detection Selection
(OT1)
0: No function
1: Continue operation after Over-torque detection
during constant speed operation
2: Stop after Over-torque detection during constant
speed operation
3: Continue operation after Over-torque detection
during RUN
4: Stop after Over-torque detection during RUN
0

06-07
Over-torque Detection Level
(OT1)
10~200% (100%: drive’s rated current)
120

06-08
Over-torque Detection Time
(OT1)
0.1~60.0 sec.
0.1

06-09
Over-torque Detection Selection
(OT2)
0: No function
1: Continue operation after Over-torque detection
during constant speed operation
2: Stop after Over-torque detection during constant
speed operation
3: Continue operation after Over-torque detection
during RUN
4: Stop after Over-torque detection during RUN
0

06-10
Over-torque Detection Level
(OT2)
10~200% (100%: drive’s rated current)
120

06-11
Over-torque Detection Time
(OT2)
0.1~60.0 sec.
0.1

06-12
Current Limit
0~200% (100%: drive’s rated current）
150

06-13
Electronic Thermal Relay
Selection (Motor 1)
0: Inverter motor (with external forced cooling)
1: Standard motor (so motor with fan on the shaft)
2: Disable
2

06-14
Electronic Thermal Characteristic
for Motor 1
30.0~600.0 sec.
60.0

06-15
Heat Sink Over-heat (OH1)
Warning
0.0~110.0℃
105.0

06-16
Stall Prevention Limit Level
0~100% (Pr.06-03, Pr.06-04)
50
06-17
Fault Record 1 (Present Fault
Record)
0: No fault record
0
06-18
Fault Record 2
1: Over-current during acceleration (ocA)
0
06-19
Fault Record 3
2: Over-current during deceleration (ocd)
0
06-20
Fault Record 4
3: Over-current during constant speed(ocn)
0
06-21
Fault Record 5
4: Ground fault (GFF)
0
