08 High-function PID Parameters
Pr.
Explanation
Settings
Factory
Setting

08-00
Input Terminal for PID Feedback
0: No function
1: Negative PID feedback: on analogue input acc. To
setting 5 of Pr. 03-00 to Pr.03-02.
2~3: Reserved
4: Positive PID feedback from external terminal AVI
(Pr.03-00)
5~8: Reserved
0

08-01
Proportional Gain (P)
0.0~100.0%
1.0

08-02
Integral Time (I)
0.00~100.00sec
1.00

08-03
Derivative Control (D)
0.00~1.00sec
0.00

08-04
Upper Limit of Integral Control
0.0~100.0%
100.0

08-05
PID Output Frequency Limit
0.0~110.0%
100.0

08-06
PID feedback value by
communication protocol
-200.00~200.00%
Read
only

08-07
PID Delay Time
0.0~35.0 sec
0.0

08-08
Feedback Signal Detection Time
0.0~3600.0 sec
0.0

08-09
Feedback Signal Fault
Treatment
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: Warn and operate at last frequency
0

08-10
Sleep Frequency
0.00 ~ 599.00Hz or 0~200.00%
0.00

08-11
Wake-up Frequency
0.00 ~ 599.00Hz or 0~200.00%
0.00

08-12
Sleep Time
0.0 ~ 6000.0sec
0.0

08-13
PID Deviation Level
1.0 ~ 50.0%
10.0

08-14
PID Deviation Time
0.1~300.0sec
5.0

08-15
Reserved

08-16
PID Compensation Selection
0: Parameter setting
1: Analog input
0

08-17
PID Compensation
-100.0~+100.0%
0
08-18
Setting of Sleep Mode Function
0: Follow PID output command
1: Follow PID feedback signal
0

08-19
Wakeup Integral Limit
0.0~200.0%
50.0
08-20
PID Mode Selection
0: Serial connection
1: Parallel connection
0
08-21
Enable PID to Change
Operation Direction
0: Operation direction can be changed
1: Operation direction can not be changed
0

08-22
Wakeup Delay Time
0.00~600.00 Seconds
0.00
