Chapter 12 Description of Parameter Settings|CFP2000 Series
12.1-02-11
55:
Motor #1 Output
56:
Motor #2 Output
57:
Motor #3 Output
58:
Motor#4 Output
59:
Motor#5 Output
60:
Motor #6 Output
6
1: Motor#7 Output
62: Motor#8 Output
63~65: Reserved
66: SO contact A (N.O.)
67: Analog input signal level achieved
68: SO contact B (N.C.)
69:
Output Command of Preheating
This parameter is used for setting the function of multi-function terminals.
Pr.02-36~Pr.02-41 requires additional extension cards to display the parameters, the choices of
optional cards are EMC-D42A and EMC-R6AA.
The optional card EMC-D42A provides 2 output terminals and can be used with Pr.02-36~02-37.
The optional card EMC-R6AA provides 6 output terminals and can be used with Pr.02-36~02-41.
Summary of function settings (Take the normally open contact for example, ON: contact is closed,
OFF: contact is open)
Settings Functions Descriptions
0 No Function
1 Operation Indication Active when the drive is not at STOP.
2
Master Frequency
Attained
Active when the AC motor drive reaches the output frequency
setting.
3
Desired Frequency
Attained 1 (Pr.02-22)
Active when the desired frequency (Pr.02-22) is attained.
4
Desired Frequency
Attained 2 (Pr.02-24)
Active when the desired frequency (Pr.02-24) is attained.
5
Zero Speed (frequency
command)
Active when frequency command =0. (the drive should be at RUN
mode)
6
Zero Speed with Stop
(frequency command)
Active when frequency command =0 or stop.
7 Over Torque 1
Active when detecting over-torque. Refer to Pr.06-07 (over-torque
detection level-OT1) and Pr.06-08 (over-torque detection
time-OT1). Refer to Pr.06-06~06-08.
8 Over Torque 2
Active when detecting over-torque. Refer to Pr.06-10 (over-torque
detection level-OT2) and Pr.06-11 (over-torque detection
time-OT2). Refer to Pr.06-09~06-11.
9 Drive Ready Active when the drive is ON and no abnormality detected.
10 Low voltage warn (Lv) Active when the DC Bus voltage is too low. (refer to Pr.06-00 low
