Delta VFD220VL43C-J User Manual

Chapter 4 Description of Parameters | VFD-VJ
4-15
Pr. Name of Parameter Setting
Factory
Setting
VF
FOCPG
FOCPM

02-11 PTC type
0: Not assigned
1: KTY84-130
2: PTC130
3: Switch (N.C. model)
0 ○ ○ ○

02-12
Motor fan activation
level
0.0~150.0°C 50.0 ○ ○ ○

02-13
Electronic thermal relay
selection 1
0: Inverter motor (Separate heat dissipating,
the cooling fan and the rotating shaft are not
synchronized)
1: Standard motor (In-lined heat dissipating,
the cooling fan and the rotating shaft are
synchronized)
2: Disable
2 ○ ○ ○

02-14
Electronic thermal
characteristic for motor
30.0~600.0 seconds 60.0 ○ ○ ○
02-15
Output frequency at
malfunction
0.00~599.00 Hz Read only ○ ○ ○
02-16
Output voltage at
malfunction
0.0~6553.5 V
Read only
02-17
Output of DC side
voltage at
malfunction
0.0~6553.5 V Read only ○ ○ ○
02-18
Output Current at
malfunction
0.00~655.35 Amp
Read only ○ ○ ○
02-19
IGBT temperature at
malfunction
0.0~6553.5 ºC
Read only ○ ○ ○
02-20 Auto-Reset LvX error 0: Disable, 1: Enable ºC 0 ○ ○ ○
02-21
Decode the parameter
protection with the
password
0~9998 0 ○ ○ ○
02-22
Set up a parameter
protection password
0~9998, 1000~65535 0 ○ ○ ○
02-23
~ 02-31
Reserved
02-32
Frequency Command at
malfunction
0.00 ~ 599.00 Hz
Read only
○ ○ ○
02-33
Capacitor’s temperature
at malfunction
-3276.7~3276.7 ºC
Read only
○ ○ ○
02-34
Motor’s rotating speed
at malfunction
-3276.7~3276.7 rpm
Read only
○ ○ ○
02-35 Torque command at -3276.7~3276.7 % Read only ○ ○ ○
