Delta VFD9A0MS43ANSHA User Manual

Chapter 9 Specification MS300 (High Speed Model)
9-3
230V series_3-phase (no built-in filter)
Model VFD_ _ _ _ _ _ _
ANSHA
ENSHA
7A5MS23 11AMS23 17AMS23
Applicable Motor Output (kW) 1.5 2.2 3.7
Applicable Motor Output (hp) 2 3 5
Output
Heavy duty
Rated Output Capacity (kVA) 2.9 4.2 6.5
Rated Output Current (A) 7.5 11 17
Carrier Frequency (kHz) 2~15 (default 6)
Input
Rated Input Current (A) Heavy Duty 9 13.2 20.4
Rated Voltage / Frequency 3-phase AC 200V~240VAC (-15% ~ +10%) / 50/60Hz
Mains Input Voltage Range (VAC) 170~264
Mains Frequency Range (Hz) 47~63
Frame B1 C1 C1
AC Drive Weight (kg) 1.05 kg 1.24 1.24
Cooling Method Fan cooling with fan kit
EMC Filter Optional
IP Rating
VFD_ _ _ _ _ _ _ ANSHA: IP20
VFD_ _ _ _ _ _ _ ENSHA: IP40*
230V series_3-phase (no built-in filter)
Model VFD_ _ _ _ _ _ _
ANSHA
ENSHA
25AMS23 33AMS23 49AMS23 65AMS23
Applicable Motor Output (kW) 5.5 7.5 11 15
Applicable Motor Output (hp) 7.5 10 15.2 20
Output
Heavy duty
Rated Output Capacity (kVA) 9.5 12.6 18.7 24.8
Rated Output Current (A) 25 33 49 65
Carrier Frequency (kHz) 2~15 (default 6)
Input
Rated Input Current (A) Heavy Duty 30 39.6 58.8 78
Rated Voltage / Frequency 3-phase AC 200V~240VAC (-15% ~ +10%) / 50/60Hz
Mains Input Voltage Range (VAC) 170~264
Mains Frequency Range (Hz) 47~63
Frame D1 E1 F1
AC Drive Weight (kg) 2.07 3.97 6.25
Cooling Method Fan cooling with fan kit
EMC Filter Optional
IP Rating
VFD_ _ _ _ _ _ _ ANSHA : IP20
VFD_ _ _ _ _ _ _ ENSHA : IP40*
NOTE
 IP40*: The IP rating of wiring area (main circuit terminals and control terminals, frame B/C/D/E/F) and the vent near capacitor (frame C/D/E/F)
is IP20.
 The value of the carrier frequency is a factory setting. To increase the carrier frequency, the current needs to be decreased. See derating
curve diagram of Pr. 06-55 for more information.
 When a load is a shock or impact load, use a higher level model.
