Delta VFD9A0MS43ANSHA

Chapter 7 Optional AccessoriesMS300 (High Speed Model)
7-39
7-12 DIN-Rail Mounting
MKM-DRB (applicable for Frame B)
Screw Torque
M4*2PCS
8~10 kg-cm
[6.9~8.7 lb-in.]
[0. 0 98 Nm]
72.0[2.83]
142.0[5.59]
8.0[0.31]
10.2[0.40]
unit: mm[inch]
4.6[0.18]
(M4 NUT)
MKM-DRC (applicable for Frame C)
Screw Torque
M5*4PCS
10~12 kg-cm
[8.7~10.4 lb-in.]
[0.98~1.18 Nm]
87.0[3.43] 8.0[0.31]
157.0[6.18]10.2[0.40]
unit: mm[inch]
5.7[0.22]
(M5 NUT)
