Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-7
Pr. Explanation Settings
Factory
Setting

01-22 JOG frequency 0.0~1500.0 Hz 6.0

01-23 1
st
/ 4
th
Accel. / decel. frequency 0.0~1500.0 Hz 0.0

01-24 S-curve acceleration begin time 1
Pr. 01-45 = 0: 0.00~25.00 sec.
Pr. 01-45 = 1: 0.0~250.0 sec.
0.20
0.2

01-25 S-curve acceleration arrival time 2
Pr. 01-45 = 0: 0.00~25.00 sec.
Pr. 01-45 = 1: 0.0~250.0 sec.
0.20
0.2

01-26 S-curve deceleration begin time 1
Pr. 01-45 = 0: 0.00~25.00 sec.
Pr. 01-45 = 1: 0.0~250.0 sec.
0.20
0.2

01-27 S-curve deceleration arrival time 2
Pr. 01-45 = 0: 0.00~25.00 sec.
Pr. 01-45 = 1: 0.0~250.0 sec.
0.20
0.2
01-28 Skip frequency 1 (upper limit) 0.0~1500.0 Hz 0.0
01-29 Skip frequency 1 (lower limit) 0.0~1500.0 Hz 0.0
01-30 Skip frequency 2 (upper limit) 0.0~1500.0 Hz 0.0
01-31 Skip frequency 2 (lower limit) 0.0~1500.0 Hz 0.0
01-32 Skip frequency 3 (upper limit) 0.0~1500.0 Hz 0.0
01-33 Skip frequency 3 (lower limit) 0.0~1500.0 Hz 0.0
01-34 Zero-speed mode
0: Output waiting
1: Zero-speed operation
2: Fmin (Refer to Pr. 01-07, 01-41)
0
01-35 Output frequency of motor 2 0.0~1500.0 Hz
600.0/
500.0
01-36 Output voltage of motor 2
230 V series: 0.0 V~255.0 V
460 V series: 0.0~510.0 V
220.0
440.0
01-37 Mid-point frequency 1 of motor 2 0.0~1500.0 Hz 0.0

01-38 Mid-point voltage 1 of motor 2
230 V series: 0.0 V~240.0 V
460 V series: 0.0 V~480.0 V
0.0
0.0
01-39 Mid-point frequency 2 of motor 2 0.0~1500.0 Hz 0.0

01-40 Mid-point voltage 2 of motor 2
230 V series: 0.0 V~240.0 V
460 V series:0.0 V~480.0 V
0.0
0.0
01-41 Min. output frequency of motor 2 0.0~1500.0 Hz 0.0

01-42 Min. output voltage of motor 2
230 V series: 0.0 V~240.0 V
460 V series: 0.0 V~480.0 V
0.0
0.0
01-43 V/F curve selection 0: V/F curve determined by Pr. 01-00~01-08 Read Only

01-44
Auto acceleration / deceleration
setting
0: Linear accel. / decel.
1: Auto accel., linear decel.
2: Linear accel., auto decel.
3: Auto accel. / decel.
4:
Linear, stall prevention by auto accel. /
decel. (limited by Pr. 01-12 to 01-21)
0
