Delta VFD9A0MS43ANSHA User Manual

Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-16
Pr. Explanation Settings
Factory
Setting

03-46 AI lower level 2 -100 % ~100.00 % 10

03-50
Analog input curve selection
0: Regular Curve
1: 3 point curve of AVI (& AI10)
2: 3 point curve of ACI (& AI11)
3: 3 point curve of AVI & ACI (& AI10 & ＡI11)
(AI10, AI11 is valid when extension card is installed)
0

03-57 ACI lowest point
03-29 = 1, 0.00~10.00 V
03-29 ≠ 1, 0.00~20.00 mA
4.00

03-58 ACI proportional lowest point 0.00~100.00 % 0.00

03-59 ACI mid-point
03-29 = 1, 0.00~10.00 V
03-29 ≠ 1, 0.00~20.00 mA
12.00

03-60 ACI proportional mid-point 0.00~100.00 % 50.00

03-61 ACI highest point
03-29 = 1, 0.00~10.00 V
03-29 ≠ 1, 0.00~20.00 mA
20.00

03-62 ACI proportional highest point
0.00~100.00 % 100.00

03-63 AVI voltage lowest point 0.00~10.00 V 0.00

03-64
AVI voltage proportional lowest
point
-100.00~100.00 % 0.00

03-65
AVI voltage mid-point
0.00~10.00 V 5.00

03-66
AVI voltage proportional mid-point -100.00~100.00 % 50.00

03-67 AVI voltage highest point 0.00~10.00 V 10.00

03-68
AVI voltage proportional highest
point
-100.00~100.00 %
100.00

03-69
Negative AVI voltage lowest point
0.00~ -10.00 V
(valid when Pr. 03-28 set as -10 V ~ +10 V)
0.00

03-70
Negative AVI voltage proportional
lowest point
-100.00~100.00 %
(valid when Pr. 03-28 set as -10 V ~ +10 V)
0.00

03-71 Negative AVI voltage mid-point
0.00~ -10.00 V
(valid when Pr. 03-28 set as -10 V ~ +10 V)
-5.00

03-72
Negative AVI voltage proportional
mid-point
-100.00~100.00 %
(valid when Pr. 03-28 set as -10 V ~ +10 V)
-50.00

03-73 Negative AVI voltage highest point
0.00~ -10.00 V
(valid when Pr. 03-28 set as -10 V ~ +10 V)
-10.00

03-74
Negative AVI voltage proportional
highest point
-100.00~100.00 %
(valid when Pr. 03-28 set as -10 V ~ +10 V)
-100.00
