Delta VFD9A0MS43ANSHA

Chapter 11 Summary of Parameter SettingsMS300 (High Speed Model)
11-20
06 Protection Parameters (1)
Pr. Explanation Settings
Factory
Setting

06-00 Low voltage level
230 V: 150.0~220.0 VDC
460 V: 300.0~440.0 VDC
180.0
360.0

06-01 Over-voltage stall prevention
0: Disabled
230 V: 0.0~450.0 VDC
460 V: 0.0~900.0 VDC
380.0
760.0

06-02
Selection for over-voltage stall
prevention
0: Traditional over-voltage stall prevention
1: Smart over-voltage stall prevention
0

06-03
Over-current stall prevention during
acceleration
Heavy Load: 0~200 %
(100 % corresponds to the rated current of the drive)
180

06-04
Over-current stall prevention during
operation
Heavy Load: 0~200 %
(100 % corresponds to the rated current of the drive)
180

06-05
Accel. / Decel. time selection of stall
prevention at constant speed
0: By current accel. / decel. time
1: By the 1
st
accel. / decel. time
2: By the 2
nd
accel. / decel. time
3: By the 3
rd
accel. / decel. time
4: By the 4
th
accel. / decel. time
5: By auto accel. / decel.
0

06-06
Over-torque detection selection
(motor 1)
0: No function
1: Continue operation after Over-torque detection
during constant speed operation
2: Stop after Over-torque detection during constant
speed operation
3: Continue operation after Over-torque detection
during RUN
4: Stop after Over-torque detection during RUN
0

06-07
Over-torque detection level
(motor 1)
110~250 % (100 % corresponds to the rated current
of the drive)
120

06-08
Over-torque detection time
(motor 1)
0.0~60.0 sec. 0.1

06-09
Over-torque detection selection
(motor 2)
0: No function
1: Continue operation after Over-torque detection
during constant speed operation
2: Stop after Over-torque detection during constant
speed operation
3: Continue operation after Over-torque detection
during RUN
4: Stop after Over-torque detection during RUN
0
