Delta VFD9A0MS43ANSHA User Manual

Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-07-9

Fan Cooling Control
Factory Setting: 3
Settings 0: Fan always ON
1: Fan will be OFF after the AC motor drive stops 1 minute
2: 2: When the AC motor drive runs, the fan is ON. When the AC motor drive
stops, the fan is OFF
3: Fan turns ON when the temperature attain around 60
o
C
 This parameter is used for controlling the fan.
 Setting 0: Fan will run immediately when the power of drive is turned ON.
 Setting 1: AC motor drive runs and fan will run.1 minute after AC motor drive stops, fan will be
OFF
 Setting 2: AC motor drive runs and fan will run. AC motor drive stops and fan will stop
immediately
 Setting 3: When temperature of IGBT is higher than 60 degrees, fan will run. When temperature
of IGBT is lower than 40 degrees, fan will stop.

Deceleration of Emergency or Forced Stop
Factory Setting: 0
Settings 0: Coast to stop
1: Stop by 1
st
deceleration time
2: Stop by 2
nd
deceleration time
3: Stop by 3
rd
deceleration time
4: Stop by 4
th
deceleration time
5: System Deceleration
6: Automatic Deceleration
 When the multi-function input terminal is set to EF (10) or forced stop (18) and the terminal
contact is ON, the drive will stop according to the setting of this parameter.

Auto Voltage Regulation (AVR) Function
Factory Setting: 0
Settings 0: Enable AVR
1: Disable AVR
2: Disable AVR during deceleration
 The rated voltage of the motor is usually AC 220V / 200 V, 60 Hz / 50 Hz, and the input voltage
of the AC motor drive may vary from AC 180 V to 264V, 50 Hz / 60 Hz. Therefore, when the AC
motor drive is used without AVR function, the output voltage will be the same as the input
voltage. When the motor runs at the voltage exceeding 12 % ~ 20 % of rated voltage, it will
cause higher temperature, damaged insulation and unstable torque output, which will result in
losses due to shorter lifetime of motor.
 AVR function automatically regulates the output voltage of AC motor drive to the motor rated
voltage. For example, if V/F curve is set at AC 200V / 50 Hz and the input voltage is at AC 200V
to 264V, then output voltage to the motor will automatically be reduced to a maximum of AC
200V / 50 Hz. If the input voltage is at AC 180V to 200V, the output voltage to motor and input
power will be in direct proportion.
