Delta VFD9A0MS43ANSHA User Manual

Chapter 8 Optional Cards MS300 (High Speed Model)
8-10
Environment
Noise immunity
ESD (IEC 61800-5-1, IEC 6100-4-2)
EFT (IEC 61800-5-1, IEC 6100-4-4)
Surge Test (IEC 61800-5-1, IEC 6100-4-5)
Conducted Susceptibility Test (IEC 61800-5-1, IEC 6100-4-6)
Operation / Storage
Operation
: -10°C ~ 50°C (temperature)，90% (humidity)
Storage: -25°C ~ 70°C (temperature)，95% (humidity)
Shock / Vibration resistance
International standards
:
IEC 61800-5-1, IEC 60068-2-6 / IEC 61800-5-1, IEC 60068-2-27
 Communication Parameters for VFD-MS300 Connected to EtherNet
When VFD-MS300 links to EtherNet, please set up the communication parameters based on the table below.
The EtherNet master will be able to read/write frequency command word and operation command word to
VFD-MS300 after the communication parameters are set.
Parameter Function Current Set Value Definition of Parameter Values
00-20
Setting for source of
frequency command
8
The frequency command is controlled by
option card
00-21
Setting for source of
operation command
5
The operation command is controlled by
option card
09-30
Decoding method for
communication
0 Decoding method for Delta AC motor drive
09-75
IP setting
0 Static IP(0) / Dynamic distribution IP(1)
09-76
IP address -1
192 IP address 192.168.1.5
09-77
IP address -2
168 IP address 192.168.1.5
09-78
IP address -3
1 IP address 192.168.1.5
09-79
IP address -4
5 IP address 192.168.1.5
09-80
Netmask -1
255 Netmask 255.255.255.0
09-81
Netmask -2
255 Netmask 255.255.255.0
09-82
Netmask -3
255 Netmask 255.255.255.0
09-83
Netmask -4
0 Netmask 255.255.255.0
09-84
Default gateway -1
192 Default gateway 192.168.1.1
09-85
Default gateway -2
168 Default gateway 192.168.1.1
09-86
Default gateway -3
1 Default gateway 192.168.1.1
09-87
Default gateway -4
1 Default gateway 192.168.1.1
 Basic Registers
BR#
R/W Content Set Value
#0 R Model name Set up by the system. The model code of CMM-MOD01=H’0203
#1 R Firmware version
Displaying the current firmware version in hex, e.g. 0100h indicates
firmware version V1.00
#2 R
Release date of the
version
Displaying the data in decimal form. 10,000s digit and 1,000s digit
are for “month”; 100s digit and 10s digit are for “day”.
For 1 digit: 0 = morning; 1 = afternoon
#11 R/W MODBUS Timeout Pre-defined setting: 500 (ms)
#13 R/W Keep Alive Time Pre-defined setting: 30 (s)
