Chapter 8 Optional Cards MS300 (High Speed Model)
8-15
Mechanical Specification
Weight 23 g
Environment
Noise immunity
ESD (IEC 61800-5-1, IEC 6100-4-2)
EFT (IEC 61800-5-1, IEC 6100-4-4)
Surge Test (IEC 61800-5-1, IEC 6100-4-5)
Conducted Susceptibility Test (IEC 61800-5-1, IEC 6100-4-6)
Operation / Storage
Operation: -10ºC ~ 50ºC (temperature), 90% (humidity)
Storage: -25ºC ~ 70ºC (temperature), 95% (humidity)
Shock / Vibration resistance
International standards:
IEC 61800-5-1, IEC 60068-2-6 / IEC 61800-5-1, IEC 60068-2-27
DeviceNet Connector
PIN Signal Color Definition
5
4
3
2
1
1 V+ Red 24VDC
2 H White Signal+
3 S - Earth
4 L Blue Signal-
5 V- Black 0V
LED Indicator & Troubleshooting
There are 3 LED indicators on CMM-DN01. POWER LED displays the status of power supply. MS LED
and NS LED are dual-color LEDs, displaying the connection status and error messages of the communication
module.
POWER LED
LED status Indication Processing Methods
On Power supply in abnormal status
Check the power supply of CMM-DN01
Off Power supply in normal status No action is required
