User's Manual - 101
Video
The Video window allows you to confi gure all video streams (the no. of stream available can be
diff erent for diff erent models). You can confi gure the following:
1. Main stream/ Sub stream: Select to confi gure two basic categorized streams.
2. Codec: video compression codec in H.264, MPEG-4, or MJPEG. Note that MPEG-4 is not
supported for Liveview.
3. Frame size: video resolution. Note that due to the limited CPU resources, you may not be
able to change the resolution to a very high value, e.g., 5MP in the 1920x1920 resolution.
4. Maximum frame rate: the highest frame rate.
5. Intra frame period: How often an I-frame will be inserted into the video stream.
6. Smart Stream II: Some newer camera models come with Smart Stream features. Please refer
to the next page for detailed information.
7. Video quality: You may either select Constant bit rate or Fixed Quality as the defi ning rules for
video transmission:
Constant bit rate Places a packet size threshold on video frames; This guarantees
the frame rate per second performance, yet image quality can
be compromised if bandwidth is not suffi cient in your network
environment.
Fixed Quality Guaranteed video quality, and to ensure image quality, some frames
may be dropped when bandwidth is not suffi cient.
When done with the confi guration, click the
Apply
button.
