Overview of units and packaged content MATRIX control panel
6 PR-2011-0110-GB • Subject to modifications • R9-03-2016
1.1 Using MATRIX control panels
In combination with the MATRIX controllers, the MATRIX control panels let you
specify setpoint values for the room air conditioning as well as the display of sta
-
tus and error messages. The features are summarized as follows:
The assignment of...
– setpoints such as room or supply air temperature
– fan operating modes such as automatic operation
– operating modes of the unit, such as day-night operation
– switching times
– system parameters
The display of...
– actual values
– unit status
– error messages
1.2 Packaged content
MATRIX OPxxC control panel:
– Control panel for flush-mounted socket installation (protection type IP20)
consisting of a front panel and a mounting plate
– Operation manual – document comprising all relevant instructions
MATRIX OPxxl control panel:
– Control panel for surface mounting (protection type IP54)
consisting of a front panel and a mounting plate, including surface-mounted
socket with cable entry through membrane grommets
– Sensor type 903.454 (IP54), R=10 kOhm/25 °C
– Operation manual – document comprising all relevant instructions
