DencoHappel MATRIX OP44C - Page 72

Operating MATRIX control panel MATRIX control panel
72 PR-2011-0110-GB • Subject to modifications • R9-03-2016
Supply-air fan Extract-air fan
Display Control mode Display Control mode
Temp. Temperature controlled -------- Without extract-air fan
Temp. Temperature controlled Offset Extract-air fan follows supply-air fan with
speed offset
Temp. Temperature controlled Factor Extract-air fan follows supply-air fan with
factor
Duct pres-
sure
Duct Pressure Control -------- Without extract-air fan
Duct pres-
sure
Duct Pressure Control Offset Extract-air fan follows supply-air fan with
speed offset
Duct pres-
sure
Duct Pressure Control Factor Extract-air fan follows supply-air fan with
factor
-------- Without supply-air fan Duct pres-
sure
Duct Pressure Control
Offset Supply-air fan follows extract-air fan with
speed offset
Duct pres-
sure
Duct Pressure Control
Factor Supply-air fan follows extract air fan with
factor
Duct pres-
sure
Duct Pressure Control
Duct pres-
sure
Duct Pressure Control Duct pres-
sure
Duct Pressure Control
Volume
flow
volume flow control -------- Without extract-air fan
Volume
flow
volume flow control Offset Extract-air fan follows supply-air fan with
speed offset
Volume
flow
volume flow control Factor Extract-air fan follows supply-air fan with
factor
-------- Without supply-air fan Volume
flow
volume flow control
Offset Supply-air fan follows extract-air fan with
speed offset
Volume
flow
volume flow control
Factor Supply-air fan follows extract air fan with
factor
Volume
flow
volume flow control
Volume
flow
volume flow control Volume
flow
volume flow control
Speed.OP Assignment of fan speed using control
panel
-------- Without extract-air fan
Speed.OP Assignment of fan speed using control
panel
Offset Extract-air fan follows supply-air fan with
speed offset
Speed.OP Assignment of fan speed using control
panel
Factor Extract-air fan follows supply-air fan with
factor
