Menu Structure OP5xx MATRIX control panel
92 PR-2011-0110-GB • Subject to modifications • R9-03-2016
1)
This menu is not available if MATRIX 4700 controls is used for standard and low-profile air handling units.
2)
This menu is only available if MATRIX 4700 controls is used with standard and low-profile air handling units.
Other menus (continued)
(
→ 49)
−
Air handling unit
2)
(→ 70)
−
Unit type (→ 71)
−
Unconfigured
Heating only
Cooling only
Heating+cooling
−
Control mode (→ 71)
−
Unconfigured
Room temperature
Supply-air temperature
Room/supply air - cascade
−
Fans (→ 71)
−
Control mode
factor
Speed offset
Maximum volume flow
−
Energy recovery (→ 75)
−
Disabled
Ecoflow 2-modulating
Ecoflow 3-modulating
Ecostat
Ecoplat
Ecorot
Ecorot 0..10 V
−
Air damper system (→ 75)
−
Disabled
Air volume flow
Mixing-air damper - automatic
M.A damper automatic + fan
Outside/extract air damper
Manual 2-point
Manual 3-point
Air volume
Automatic 2-point
Autom.+fan 2-point
Automatic 3-point
Autom.+fan 3-point
−
Electric heater (→ 76)
−
Disabled
1-speed
2-speed
3-speed
0..10 V
2..10 V
0..10 V+1-speed
0..10 V+2-speed
0..10 V+3-speed
2..10 V+1-speed
2..10 V+2-speed
2..10 V+3-speed
−
Direct evaporator (→ 76)
−
Disabled
1-speed
2-speed
0..10 Volt
10..0 Volt
−
Sensor inputs (→ 75)
−
Use
Input type
Range start
Range end
Filter constant end
K-factor
−
Service (→ 79)
−
Sensor offset value (→ 80)
−
Offset value in °C or °F
−
Version info (→ 80)
−
Serial, Firmware, Hardware,
Bus system
−
Change password (→ 80)
−
Full blocking (→ 81)
−
Enter password
−
Partial blocking (→ 81)
−
Enter password
