Denon AVR-1312 Getting Started

30
Input Setup
Perform settings related to input source playback.
•You do not have to change the settings to use the unit. Make settings when needed.
Menu operation
1
Press MENU.
The menu is displayed on the TV screen.
2
Use ui to select “Input Setup”, and then press ENTER.
3
Use ui to select the menu to be set or operated.
4
Press ENTER to enter the setting.
•To return to the previous item, press RETURN B.
•Exiting the Menu, press MENU while the menu is displayed.
The menu display disappears.
Important information
nAbout the display of input sources
In this section, the configurable input sources for each item are shown as follows.
BD
DVD TV SAT/CBL GAME V.AUX DOCK TUNER
Items that can be set with the “Input Setup” procedure
Input Assign (vpage31)
Auto Preset (vpage32)
Preset Skip (vpage32)
Video Select (vpage32)
Input Mode (vpage32)
Source Level (vpage33)
Playback Mode (vpage33)
Basic version
Advanced version
Information
Advanced version
BD

Denon AVR-1312 Specifications

General

Number of Channels	5.1
HDMI Inputs	4
HDMI Outputs	1
Amplification Type	Discrete
Input Sensitivity	200 mV
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Signal-To-Noise Ratio	98 dB
Digital Optical Inputs	2
Coaxial Digital Input	1
Analog Audio Inputs	4
Headphone Jack	Yes
Tuner Presets	56
Dimensions (W x H x D)	434 x 151 x 319 mm
Amplifier Type	Discrete
Tuner Type	AM/FM
Preset Stations	56
Remote Control	Yes
Dolby Technologies	Dolby Digital Plus, Dolby Pro Logic II, Dolby TrueHD
DTS Technologies	DTS-HD Master Audio
Output Power / Channel	75 W (8 Ohms, 20 Hz - 20 kHz, 2 channels driven, THD 0.08%)
Input Impedance	47 kOhms
Audio Inputs	2 Optical, 1 Coaxial, 4 Analog
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
