Denon AVR-1513 Service Manual

100
Pin Pin Name Symbol I/O Pullup STBY stop Function
102 PA10 UPDATE_RX I - I O/L UPDATE RX
103 PA11 RESERVED O(L) - - - RESERVED
104 PA12 RESERVED O(L) - - - RESERVED
105 PA13 DEBUG I - - - JTMS / SWDIO
106 PCAP_2 - - - - Not Connected
107 VSS_2 - - - - GND
108 VDD_2 - - - - 3.3V
109 PA14 DEBUG I - - - JTCK / SWCLK
110 PA15 DEBUG I - - - JTDI
111 PC10 NC O(L) - - - NC
112 PC11 NC O(L) - - - NC
113 PC12 HDMI_DEBUG_TX O - O/L O/L HDMI DEBUG TX
114 PD0 VFD_RST O - O/L O/L VFD_RESET(Low Active)
115 PD1 HP_RLY O - O/L O/L H/P RLY Control
116 PD2 HDMI_DEBUG_RX I - I O/L HDMI DEBUG RX
117 PD3 WAKE_UP I M3VPu I I WAKE UP(Not use)
118 PD4 HP_DET I M3VPu O/L O/L H/P DETECT
119 PD5 GRN_LED O - O/L O/L 2COLOR LED GREEN
120 VSS_10 - - - - GND
121 VDD_10 - - - - 3.3V
122 PD6 NC O(L) - - - NC
123 PD7 REMOTE_IN I - I O/L REMOTE input
124 PG9 NC O(L) - - - NC
125 PG10 EEPROM_SDA I/O M3VPu I O/L EEPROM SDA
126 PG11 EEPROM_SCL O M3VPu O/L O/L EEPROM SCL
127 PG12 DAC_MUTE O - O/L O/L DAC Mute Control
128 PG13 TUNER_SCLK O - O/L O/L TUNER SCLK
129 PG14 TUNER_SDIO I/O - O/L O/L TUNER SDIO
130 VSS_11 - - - - GND
131 VDD_11 - - - - 3.3V
132 PG15 NC O(L) - - - NC
133 PB3 DEBUG O - - - JTDO / TRACESWO
134 PB4 DEBUG I - - - NJTRST
135 PB5 SUB MUTE O - O/L O/L Sub Woofer MUTE Control
136 PB6 NC O(L) - - - NC
137 PB7 NC O(L) - - - NC
138 BOOT0 BOOT0 I PullDown I I UPDATE BOOT(HIGH:UPDATE / LOW:NORMAL MODE)
139 PB8 TUNER_CE O - O/L O/L TUNER CE
140 PB9 TUNER_INT I - I O/L TUNER INTERRUPT
141 PE0 TUNER_RST O - O/L O/L TUNER Reset
142 PE1 RED_LED O - O/L O/L 2COLOR LED RED
143 VSS_3 - - - - GND
144 VDD_3 - - - - 3.3V

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
