Denon AVR-1513 Service Manual

99
Pin Pin Name Symbol I/O Pullup STBY stop Function
36 PA2 NC O(L) - - - NC
37 PA3 NC O(L) - - - NC
38 VSS_4 - - - - GND
39 VDD_4 - - - - 3.3V
40 PA4 DSP_CS O - O/L O/L DSP Chip Select
41 PA5 DSP_CLK O D3VPu O/L O/L DSP_CLK
42 PA6 DSP_MISO I D3VPu O/L O/L DSP MISO
43 PA7 DSP_MOSI O - O/L O/L DSP MOSI
44 PC4 NC O(L) - - - NC
45 PC5 NC O(L) - - - NC
46 PB0 DIR_MISO I - O/L O/L DIR_MISO
47 PB1 DIR_CLK O D3VPu O/L O/L DIR_CLK
48 PB2 / BOOT1 BOOT1 I - - - GND
49 PF11 DIR_MOSI O - O/L O/L DIR MOSI
50 PF12 DSP_RST O - O/L O/L DSP Reset
51 VSS_6 - - - - GND
52 VDD_6 - - - - 3.3V
53 PF13 DSP_MODE_SEL I/O PullDown O/L O/L DSP_MODE_SEL
54 PF14 CODEC_MUTE I(FT) - O/L O/L CODEC Mute Detect (*FT = 5V tolerant)
55 PF15 DIR_RST O - O/L O/L DIR Reset
56 PG0 DIR_CE O - O/L O/L DIR Chip Select
57 PG1 DSP_SPC1_IRQ I D3VPu O/L O/L DSP INTERRRUPTQ
58 PE7 DSP_PCP_BSY I D3VPu O/L O/L DSP BSY
59 PE8 NC O(L) - - - NC
60 PE9 HDMI_SW O - O/L O/L HDMI Audio Data MCLK Select SW
61 VSS_7 - - - - GND
62 VDD_7 - - - - 3.3V
63 PE10 NC O(L) - - - NC
64 PE11 HDMI_SPI_MISO I - I O/L HDMI OSD DATA input
65 PE12 HDMI_SPI_MOSI O - O/L O/L HDMI OSD DATA output
66 PE13 HDMI_SPI_CS O +3VHPu O/L O/L HDMI OSD Chip Select
67 PE14 HDMI_SPI_CLK O - O/L O/L HDMI OSD Clock
68 PE15 HDMI_SPI_HOLD O - O/L O/L HDMI OSD HOLD Control
69 PB10 HDMI_RST O - O/L O/L HDMI Reset
70 PB11 NC O(L) - - - NC
71 VSS_1 - - - - GND
72 VDD_1 - - - - 3.3V
73 PB12 RESERVED O(L) - - - RESERVED
74 PB13 RESERVED O(L) - - - RESERVED
75 PB14 HDMI_INT_TX_7623 I +3VHPu I O/L HDMI INT TX interrupt
76 PB15 RESERVED O(L) - - - RESERVED
77 PD8 HDMI_TXEN O - O/L O/L FRONT HDMI BUFFER(AD8195) Output Enable
78 PD9 NC O(L) - - - NC
79 PD10 NC O - O/L O/L Option(STANDBY CEC MODE Control)
80 PD11 HDMI_INT I +3VHPu I O/L HDMI INT interrupt
81 PD12 HDMI_INT2 I +3VHPu I O/L HDMI INT2 intreeupt
82 PD13 HDMI_SDA I/O +3VHPu O/L O/L HDMI SDATA
83 VSS_8 - - - - GND
84 VDD_8 - - - - 3.3V
85 PD14 HDMI_SCL O - O/L O/L HDMI SCL
86 PD15 PWR_FAIL_PROTECT I M3VPu O/L O/L +12V/-12V CHECK PROTECTION
87 PG2 THERMALDET_B I M3VPu O/L O/L TEMPERATURE PROTECTION
88 PG3 THERMALDET_A I M3VPu O/L O/L TEMPERATURE PROTECTION
89 PG4 ASO_DET I M3VPu O/L O/L ASO_DETECT
90 PG5 POWER_ON O - O/L O/L POWER RELAY Control
91 PG6 NC I - I O/L Option(CEC MODE Interrupt)
92 PG7 VOL+ I - O/L O/L VOLUME UP
93 PG8 VOL- I - O/L O/L VOLUME DOWN
94 VSS_9 - - - - GND
95 VDD_9 - - - - 3.3V
96 PC6 RESERVED O(L) - - - RESERVED
97 PC7 VFD_CE O - O/L O/L VFD_CE
98 PC8 VFD_CLK O - O/L O/L VFD_CLK
99 PC9 RESERVED O(L) - - - RESERVED
100 PA8 VFD_DATA O - O/L O/L VFD_DATA
101 PA9 UPDATE_TX O - O/L O/L UPDATE TX

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
