Denon AVR-1513 Service Manual

121
Ref. No. Part No. Part Name Remarks Q'ty New
R5708 00MGD05153160 RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T
R5711 00MGD05122160 RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T
R5712,5713 00MGD05222160 RES,CARBON(1/5W,2.2Kohm,J) CRD20TJ222T
R5715-5717 nsp RES,M-OXIDEFILM(1W/2.2Kohm) CRG1SANJ222RT
R5721-5725 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5726,5727 nsp RES,M-OXIDEFILM(2W/470ohm) CRG2SANJ471RT
VR510 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
VR520 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
VR530 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
VR540 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
VR550 963161012400S RES,SEMIFIXED(1K,BCURVE) CVN1RA102B03T
CAPACITORS GROUP
C5101 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T
C5102 nsp CAP,CERAMIC(50V/470pF/K) CCKT1H471KB
C5103 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC
C5104 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT
C5105 943134501770S CAP,ELECT(50V/220uF) CCEA1HH221T *
C5106 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC
C5107 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T
C5108 943134501780S CAP,ELECT(KR1,47uF/63V,8X11.5) CCEA1JKR1470T *
C5109 nsp SEMICONDUCTOR CAP 0.1uF 50V ZF CCFT1H104ZF
C5201 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T
C5202 nsp CAP,CERAMIC(50V/470pF/K) CCKT1H471KB
C5203 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC
C5204 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT
C5205 943134501770S CAP,ELECT(50V/220uF) CCEA1HH221T *
C5206 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC
C5207 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T
C5208 943134501780S CAP,ELECT(KR1,47uF/63V,8X11.5) CCEA1JKR1470T *
C5209 nsp SEMICONDUCTOR CAP 0.1uF 50V ZF CCFT1H104ZF
C5301 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T
C5302 nsp CAP,CERAMIC(50V/470pF/K) CCKT1H471KB
C5303 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC
C5304 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT
C5305 943134501770S CAP,ELECT(50V/220uF) CCEA1HH221T *
C5306 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC
C5307 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T
C5308 943134501780S CAP,ELECT(KR1,47uF/63V,8X11.5) CCEA1JKR1470T *
C5309 nsp SEMICONDUCTOR CAP 0.1uF 50V ZF CCFT1H104ZF
C5401 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T
C5402 nsp CAP,CERAMIC(50V/470pF/K) CCKT1H471KB
C5403 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC
C5404 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT
C5405 943134501770S CAP,ELECT(50V/220uF) CCEA1HH221T *
C5406 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC
C5407 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T
C5408 943134501780S CAP,ELECT(KR1,47uF/63V,8X11.5) CCEA1JKR1470T *
C5409 nsp SEMICONDUCTOR CAP 0.1uF 50V ZF CCFT1H104ZF
C5501 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T
C5502 nsp CAP,CERAMIC(50V/470pF/K) CCKT1H471KB
C5503 nsp CAP,CERAMIC(50V/82pF/J) CCCT1H820JC
C5504 nsp CAP,MYLAR(50V/2200pF/J) HCQI1H222JZT
C5505 943134501770S CAP,ELECT(50V/220uF) CCEA1HH221T *
C5506 nsp CAP,CERAMIC(50V/33pF/J) CCCT1H330JC
C5507 943134500070S CAP,ELECT(100V/10uF) CCEA2AH100T
C5508 943134501780S CAP,ELECT(KR1,47uF/63V,8X11.5) CCEA1JKR1470T *
C5509 nsp SEMICONDUCTOR CAP 0.1uF 50V ZF CCFT1H104ZF
C5605,5606 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT
C5607,5608 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT
C5609-5611 nsp CAP,MYLAR(50V/0.018pF/J) HCQI1H183JZT
C5612-5614 nsp CAP,MYLAR(50V/1500pF/J) HCQI1H152JZT
C5701 nsp CERAMIC CAP 0.01uF 50V ZF CCFT1H103ZF
C5702,5703 nsp CAP,METALPEFILM(250V/0.1uF) KCME2E104JP04T
C5704 943134010460S CAP,ELECT(30X35)WITHOUTPLATEONTHETOP CCET63VKL5682NKZ

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
