Denon AVR-1513 Service Manual

122
Ref. No. Part No. Part Name Remarks Q'ty New
C5706 943134010460S CAP,ELECT(30X35)WITHOUTPLATEONTHETOP CCET63VKL5682NKZ
C5707 943134010470S CAP,ELECT(50V/0.1uF) CCEA1HH0R1T
C5708 943134010480S CAP,ELECT(100V/100uF) CCEA2AH101E
C5710 nsp SEMICONDUCTOR CAP 0.1uF 50V ZF CCFT1H104ZF
C5711 943134010660S CAP,ELECT(6.3V/470uF) CCEA0JH471T
C5712 nsp SEMICONDUCTOR CAP 0.1uF 50V ZF CCFT1H104ZF
C5713 943134010660S CAP,ELECT(6.3V/470uF) CCEA0JH471T
C5716 963134010980S CAP,ELECT(16V/47uF) CCEA1CH470T
C5717 00D9430175108 CAP,ELECT(50V/10uF) CCEA1HH100T
C5718-5722 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT
C5723 00D9430175108 CAP,ELECT(50V/10uF) CCEA1HH100T
OTHERS PARTS GROUP
BK501 nsp BRACKET,PCB CMD1A569
BN501 nsp WIRE ASS'Y CWB1B013150HC *
BN502 nsp WIRE ASS'Y CWB1B007150HC *
BN505 nsp WIRE ASS'Y CWB4B003250HC *
BN508 nsp PINHEADER(11P,1.25mm,STRAIGHT,B-TO-B) CJP11GI281Z
CN503 nsp WAFER(3.96MM) CJP03GA148ZW
CN510 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN520 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN530 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN540 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
CN550 nsp WAFER/STRAIGHT/2.5mm/2P CJP02GA01ZY
ET501 nsp EARTH PALTE HJT1A025
JK503 943643101580S JACK,NOSPCC4PRR/BB(PUSH,94V-0) CJJ5P014U *
JK504 943646010230S JACK,NOSPCC6PRRR/BBB(PUSH,94V-0) CJJ5R004U
L5101 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5201 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5301 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5401 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD *
L5501 943115100310S COIL,SPEAKER(0.5UH) CLEY0R5KAD *
RY560 943682000810S RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU
RY562-564 943682100270S RELAY,981-2A-12DS,DC12V,2C1P CSL3A022ZU *
TU500 943183100230S TUNER,FM(SCREW:FTYPE),AM,SI4730-D60 E3 CNVYST990-A9U0 *
TU500 943183100240S TUNER,RDS,FM(PALTYPE),AM,SI4731-D60 E2 CNVYST990-D5E0 *
TU500 943183100250S TUNER,NORDS,FM(PALTYPE),AM,SI4730-D60 E1C CNVYST990-A2J0 *

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
