Denon AVR-1513 Service Manual

88
Ref. No. Part No. Part Name Remarks Q'ty New
P3 943412100720D KNOB,VOLUME SP CBN1A263C73 1 *
P4 943446100590D PLATE,VOLUMEKNOB CGX1A469 1 *
P5 42151002100AD DENON BADGE
BK CGB1A247H67 1 *
P5 42151002101AD DENON BADGE
SP --- 1 *
P6 943402102050D PANEL,FRONT
E3 CGW1A519RHZB63 1 *
P6 943402102060D PANEL,FRONT
E2 CGW1A519RHYB63 1 *
P6 943402102070D PANEL,FRONT
BKE1C CGW1A519RHXB63 1 *
P6 943402102080D PANEL,FRONT
SPE1C CGW1A519RGZG45 1 *
P7 943423100310D INDICATOR,POWER CGL1A299 1 *
P8 943411101750D BUTTON,POWER
BK CBT1A1167 1 *
P8 943411101760D BUTTON,POWER
SP CBT1A1167C73 1 *
P9 943411101770D BUTTON,10KEY CBT1A1164 1
*
P10 943407100020D FOOT CKL1A190 4
P11 00D9430202902 CUSHION,FOOT CHG2A289 4
P12 nsp HOLDER,PCB CHE170 2
P13 943419100250D SHEET,TOP
BK CGX1A492Z 2
P13 943419100260D SHEET,TOP
SP CGX1A492Y 2
P14 45451000500AM STOPPER,SHEET
BK CMH1A306Z 8
P14 45451000501AM STOPPER,SHEET
SP CMH1A306Y 8
P15 nsp BUSHING,ACCORD
E3,E1C CHR1A028 1
★
P16
nsp CLAMPER CHR301 5
★
P17 nsp CUSHION CHG1A439 1
★
P18 nsp LABEL,HOT
E3 CQB1A906Z 1
★
P19 nsp LABEL,POP
E3,E2 CQB1A1095Z 1 *
★
P19 nsp LABEL,POP
E1C CQB1A1099Z 1 *
★
P20 nsp TAPE,HEMELON CHS1A032 -
M1 nsp EARTH,HDMI CMC1A422 1
M2 nsp EARTHPLATE,HDMI CMC1A431 1 *
M3 nsp EARTHPLATE,USB CMC1A430 2 *
M4 nsp CHASSIS,BOTTOM CUA1A335 1 *
M5 943403100570D CABINET,TOP BK CKC1A215K117 1 *
M5 943403100580D CABINET,TOP SP CKC1A215D11 1 *
M6 nsp BRACKET,PCB CMD1A398 1
M7 nsp HEATSINK CMY1A381 1 *
M8 nsp BRACKET,H/SPCB CMD1A802 2 *
M9 nsp BRACKET,PCB CMD1A774 2
M10 nsp SMPS BRACKET CMD1A790 1
M11 nsp PANEL,REAR
E3 CKF1A454Z 1 *
M11 nsp PANEL,REAR
E2 CKF2A454Z 1 *
M11 nsp PANEL,REAR
E1C CKF1A454Y 1 *
SCREWS
S1 nsp SCREW,SPECIAL CHD1A012ZR 15
S2 nsp SCREW CTWS3+10GR
1
S3 nsp SCREW
CTB3+6JR 12
S4
nsp SCREW CTB3+10JR 19
S5 nsp SCREW CTBD3+8JFZR 14
S6 nsp SCREW BK CTBD4+8JFZR 6
S6 nsp SCREW
SP CTBD4+8JFN 6
S7 nsp SCREW CTBD3+6FFZR 11

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
