Denon AVR-1513 Service Manual

89
Ref. No. Part No. Part Name Remarks Q'ty New
S8 nsp SCREW CTW3+8JR 13
S9 nsp SCREW CTW3+12JR 2
S10 nsp SCREW,TRANS CHDR1A023R 4
S11 nsp SCREW
BK CTBD3+8JFZR 3
S11 nsp SCREW
SP CTBD3+8JFN 3
S12 nsp SCREW
BK CTB3+8JFZR 6
S12 nsp SCREW
SP CTB3+8JFN 6
S13 nsp SCREW CTB3+6FR 4
S15 nsp SCREW CTW3+6JR 2
S16 nsp SCREW,SPECIAL CHD4A012R 3
WIRES
★
H1 943606501530S CARD,CABLE
23P, L=180mm CWC5C4A23B180B10 1 *
★
H2 943606501540S CARD,CABLE
23P, L=330mm CWC5F4A23A330B08 1 *
★
H3 nsp WIRE ASS'Y
3T LUG WIRE CWE8102050RR 1

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
