Denon AVR-1708 Service Manual

10
AVR-1708/1508/688/588/488 AVC-1508
DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
下記フロー図の矢印の順番にはずしてください。
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
再組み立ての場合は、下記のフローの逆の順番に組立ててください
• In the case of the re-assembling, observe "attention of assembling" it.
再組み立ての場合は、「組立のご注意」を遵守してください。
CABINET TOP
PANEL FRONT ASSY CHASSIS BACK ASSY TRANS
Refer to "DISASSEMBLY 1.PANEL FRONT ASSY" Refer to "DISASSEMBLY 2.CHASSIS BACK ASSY" Refer to "DISASSEMBLY 6.TRANS"
and "EXPLODED VIEW" and "EXPLODED VIEW" and "EXPLODED VIEW"
9 : POWER SW ASSY 55 : SPEAKER ASSY
10 : FUNCTION ASSY 71 : TUNER PACK
11 : FRONT ASSY
14 : HEAD PHONE ASSY
CPU ASSY
21 : V. AUX ASSY Refer to "DISASSEMBLY 3.HDMI PWB ASSY"
22 : MIC ASSY and "DISASSEMBLY 4.CPU ASSY"
and "EXPLODED VIEW"
51 : CPU PWB ASSY
52 : INPUT PWB ASSY
53 : VIDEO PWB ASSY
54 : HDMI PWB ASSY
CHASSIS MAIN ASSY
Refer to "DISASSEMBLY 5.CHASSIS MAIN ASSY"
and "EXPLODED VIEW"
33 : 2CH PWB ASSY
50 : MAIN PWB ASSY
56 : POWER SUPPLY PWB ASSY
57 : POWER PWB ASSY

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
