Denon AVR-1708 Service Manual

105
AVR-1708/1508/688/588/488 AVC-1508
AVR-1708 E3 model
C18,19 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C20 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C21 nsp C,CERAMIC 100PF-J/50V D010101167160S
C22 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C23 nsp C,CERAMIC 100PF-J/50V D010101167160S
C24,25 nsp C,ELECT 10UF-MVG/16V D050100083460S
C26,27 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C28H nsp C,ELECT 10UF-MVG/16V D050100083460S
C29H nsp C,ELECT 10UF-MVG/16V D050100083460S
C30H nsp C,ELECT 10UF-MVG/16V D050100083460S
C33-36 nsp C,CERAMIC 20PF-J/50V D010200167160S
C37-39 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C40 nsp C,ELECT 22UF-MV/6.3V D050220081450S
C41 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C42,43 nsp C,CERAMIC 5PF-C/50V D010050107160S
C44 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C45 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C46 nsp C,CERAMIC 4.7UF-K/10V D011475572200S
C47-50 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C51 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C52 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C53 nsp C,ELECT 10UF-MVG/16V D050100083460S
C54 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C55 nsp C,CERAMIC 4.7UF-K/10V D011475572200S
C56,57 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C58 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C59 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C60 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C61 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C62 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C63-65 nsp C,CERAMIC 100PF-J/50V D010101167160S
C66 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C68 nsp C,ELECT 0.1UF-MVG/50V D050R10080010S
C69,70 nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C71,72 nsp C,ELECT 22UF-MV/6.3V D050220081450S
C73,74 nsp C,ELECT 10UF-MVG/16V D050100083460S
C75 nsp C,CERAMIC 560PF-J/50V D010561167160S
C76 nsp C,CERAMIC 1800PF-K/50V D011182777160S
C77,78 nsp C,CERAMIC 560PF-J/50V D010561167160S
C79 nsp C,CERAMIC 1800PF-K/50V D011182777160S
C80 nsp C,CERAMIC 560PF-J/50V D010561167160S
C82 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C85,86 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C87,88 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C831D nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C832D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C833D nsp C,CERAMIC 100PF-J/50V D011101167101S
C834D nsp C,CERAMIC 100PF-J/50V D011101167101S
C835D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C836D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C837D nsp C,CERAMIC 100PF-J/50V D011101167101S
C838D nsp C,CERAMIC 100PF-J/50V D011101167101S
C839D nsp C,CERAMIC 100PF-J/50V D011101167101S
C840D nsp C,CERAMIC 100PF-J/50V D011101167101S
C841D nsp C,CERAMIC 100PF-J/50V D011101167101S
C842D nsp C,CERAMIC 100PF-J/50V D011101167101S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
