Denon AVR-1708 Service Manual

106
AVR-1708/1508/688/588/488 AVC-1508
AVR-1708 E3 model
C843D nsp C,CERAMIC 100PF-J/50V D011101167101S
C844D nsp C,CERAMIC 100PF-J/50V D011101167101S
C845D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C846D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C847D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C848D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C849D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C850D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C851D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C852D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C853D nsp C,CERAMIC 1000PF-K/50V D011102177101S
C854D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C855D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C856D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C857D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C858D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C859D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C860D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C861D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C862D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C863D nsp C,CERAMIC 100PF-J/50V D011101167101S
C864D nsp C,CERAMIC 4.7UF-K/10V D011475572200S
C865D nsp C,CERAMIC 5PF-C/50V D010050107160S
C866D nsp C,CERAMIC 5PF-C/50V D010050107160S
C871D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C873D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C875D nsp C,CERAMIC 4.7UF-K/10V D011475572200S
C876D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C877D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C878D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C879D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C880D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C881D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C882D nsp C,CERAMIC 6PF-D/50V D010060117160S
C883D nsp C,CERAMIC 6PF-D/50V D010060117160S
C884D nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C885D nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C886D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C887D nsp C,FILM 0.12UF-J/63V D020124078060S
C888D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C889D nsp C,CERAMIC 100PF-J/50V D011101167101S
C890D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C891D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C892D nsp C,CERAMIC 4.7UF-K/10V D011475572200S
C893D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C895D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C896D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C897D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C898D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C899D nsp C,CERAMIC 100PF-J/50V D011101167101S
C900D nsp C,CERAMIC 4.7UF-K/10V D011475572200S
C901D nsp C,ELECT 100UF-MVG/6.3V D050101081650S
C902D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C903D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C904D nsp C,CERAMIC 5600PF-K/50V D011562777160S
C905D nsp C,CERAMIC 390PF-J/50V D010391167160S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
