Denon AVR-1708 Service Manual

107
AVR-1708/1508/688/588/488 AVC-1508
AVR-1708 E3 model
C906D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C907D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C908D nsp C,ELECT 47UF-MVG/6.3V D050470081460S
C909D nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C910D nsp C,ELECT 10UF-MVG/16V D050100083460S
C911D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C913D nsp C,ELECT 10UF-MVG/16V D050100083460S
C914D nsp C,CERAMIC 0.01UF-K/50V D011103177101S
C915D nsp C,ELECT 10UF-MVG/16V D050100083460S
C916D nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C917D nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C918D nsp C,CERAMIC 0.1UF-K/50V D011104577162S
C919D nsp C,CERAMIC 0.1UF-K/50V D011104577162S
OTHERS PARTS GROUP
BD801-804 nsp COIL,BEAD MB-160808 D340160800060S
BD807D nsp COIL,BEAD MB-160808 D340160800060S
BD808D-02 nsp COIL,BEAD MB-160808 D340160800060S
CB03 nsp R THICK 0-J,1/16W C20000006M160S
CB06 nsp COIL,BEAD MB-160808 D340160800060S
CN01 nsp CN.WAFER 16P L101100031610S
CN802 nsp CN.HOUSING 16P L120912160010S
CN803 nsp CN.WAFER 16P L101100031610S
CN804 nsp CN.HOUSING 15P L120912150010S
CN805 nsp CN.HOUSING 08P L120912080010S
CP201 nsp CN.WAFER 9P L101220090000S
CP404 nsp CN.WAFER 4P L101220040000S
CP405 nsp CN.WAFER 5P L101220050000S
CP406 nsp CN.WAFER 3P L101220030000S
CP904 nsp CN.WAFER 6P L101220060010S
J806 nsp R,CHIP THICK 0-J,1/16W C20000006M101S
JACK01-03 00D 963 0388 504 19PIN HDMI CONNECTOR L109100190020S
JACK04 nsp CAM-D96 4PIN SMALL COCNNETOR L109040000020S
X01 nsp CRYSTAL CHIP FCX-02(45.1584MHz) E80545R150020S
X803D nsp FCX-03(16.660MHz) 00D3991091905
X804D nsp FCX-03(24.576MHz) 00D3991053901
LUG901 nsp RING,TER WIRE 70MM/1P 8410700010070S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
