Denon AVR-1708 Service Manual

108
AVR-1708/1508/688/588/488 AVC-1508
AVR-1708 E3 model
VIDEO P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1001 00D 963 0133 500 IC BA7626FP J171762600010S
IC1002 00D 963 0068 002 IC BU4052BCF-E2 J040405200060S
IC1003 00D 963 0074 504 IC BU2090F-E2 J044209000010S
IC1005,1006 00D 963 0133 500 IC BA7626FP J171762600010S
IC1007 00D 963 0068 002 IC BU4052BCF-E2 P J040405200060S
IC1008 00D 963 0340 801 IC NJW1321FP1 J171132100010S
IC1011,1012 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1013 00D 963 0367 503 IC SE1117-1.8 J126111718010S *
IC1014 00D 963 0111 603 IC SE1117-33-PF J126111733020S
IC1016 00D 963 0295 406 IC IC BH7868FS J127786800000S
IC1017 00D 262 3425 905 LTC4300-2CMS8 J040430000000S
IC1018 00D 262 3643 004 ADV7180BSTZ J044718000010S
IC1019 00D 262 3644 003 ADV7172KSTZ J045717200011S
IC1151 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1157 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1160 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1162,1163 00D 263 1082 903 TK15420MTL +C J127154200010S
IC1164 00D 963 0327 604 IC NJM2581M J127258100010S
Q1001 00D 963 0148 508 TRKTA1504S J520015040150S
Q1002 00D 960 0296 309 TR KRC111S (NM) J522011100210S
Q1003,1004 00D 963 0120 704 TR KRA102S J520010200210S
Q1005,1006 00D 963 0102 803 TR 2SA933S J5000933S0050S
Q1011,1012 00D 963 0120 704 TR KRA102S J520010200210S
Q1013,1014 00D 963 0148 508 TRKTA1504S J520015040150S
Q1015,1016 00D 960 0296 309 TR KRC111S (NM) J522011100210S
Q1017 00D 963 0120 801 TR KRC102S J522010200210S
Q1018 00D 963 0121 606 TR KRC107S J522107S00210S
Q1019 00D 963 0102 803 TR 2SA933S J5000933S0050S
Q1020 00D 960 0285 006 TR KRC104S J522104S00210S
Q1021-1025 00D 963 0148 508 TRKTA1504S J520015040150S
Q1026 00D 960 0285 006 TR KRC104S J522104S00210S
D1001 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D1005 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D1009,1010 00D 963 9006 599 R,CHIP THICK 0-J,1/10W C200000060200S
D1011-1014 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D1021-1024 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
RESISTORS GROUP
R1008 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R1096 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R1100 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
VR1001-1005 00D 963 0367 606 R,CHIP THICK 100ohm 1/16W C20001014M160S
CAPACITORS GROUP
C1002-1004 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C1005 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070S
C1006 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1007,1008 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1009 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
