Denon AVR-1708 Service Manual

152
AVR-1708/1508/688/588/488 AVC-1508
AVR-688 E3 model
C751E 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751F 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751G 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751H 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751J 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751K 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751L 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751M 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751N 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751P 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751Q 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751R 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751S 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751T 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751U 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C751V 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C752 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C752A nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752B nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752C nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752D nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752E nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752F nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752G nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752H nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752J nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752K nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752L nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752M nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752N nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752P nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752Q nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752R nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752S nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752T nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752U nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752V nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C752W nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C752X nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C753-771 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C772,773 00D 963 0293 806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C774 nsp C,FILM 0.15UF-K/63V D020154078060S
C775 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C776 00D 960 9008 640 C,FILM 0.022UF-J/100V D02022306C060S
C777 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C778,779 nsp C,CERAMIC 100PF-J/50V D010101167160S
C780 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C781 00D 960 9008 640 C,FILM 0.022UF-J/100V D02022306C060S
C782 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C783 nsp C,FILM 0.15UF-K/63V D020154078060S
C784-790 00D 963 0293 806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C791-793 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C794 00D 963 0293 806 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C795-799 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C800,801 00D 960 9010 832 C,ELECT 10UF-M/16V D040100083050S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
