Denon AVR-1708 Service Manual

153
AVR-1708/1508/688/588/488 AVC-1508
AVR-688 E3 model
OTHERS PARTS GROUP
CLAMP501 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN514 nsp CN,WIRE 13P L000181130010S
CN702 nsp CN.HOUSING 15P L120912150010S
CN703 nsp CN.WAFER 8P L101100030810S
CN704 nsp CN.WAFER 19P L101100031910S
CN706 nsp CN,WIRE 8P L000121080010S
CP704 nsp CN.WAFER 15P L101220150000S
JACK701 00D 963 0132 103 TER,RCA 4PIN G602405B0400YS
JACK702 00D9630387505 TER,RCA 4PIN G602405B5500YS
JACK703 00D 963 0132 103 TER,RCA 4PIN G602405B0400YS
JACK704,705 00D 963 0132 307 TER,RCA 6PIN G603603B05000S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
