Denon AVR-1708 Service Manual

241
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 EUT model
R414SBL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R414SBR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R415SBL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R415SBR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R419SBL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R419SBR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R420SBL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R420SBR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R421SBL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R421SBR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R422SBL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R422SBR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R423SBL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R423SBR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R424SBL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R424SBR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R429SBL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R429SBR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R430SBL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R430SBR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
VR401,402 00D 963 0366 407 VR,SEMI CARBON EVN-DCAA03B 1KB C541102315000S
CAPACITORS GROUP
C401D 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C401H 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C401SBL 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C401SBR 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C401X nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C402D 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C402H 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C402SBL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C402SBR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C402X 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C403D 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C403H 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C403SBL 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS
C403SBR 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS
C404D 00D 960 0133 404 C,ELECT 10000UF 16V D040103083020S
C404H 00D 963 0217 002 C,ELECT 3300UF-M/16V D040332083010S
C404SBL 00D 963 0338 208 C,CERAMIC 470PF-K/500V D00447127D050S
C404SBR 00D 963 0338 208 C,CERAMIC 470PF-K/500V D00447127D050S
C404X 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
C405D 00D 963 0338 402 C,ELECT 330UF-M/6.3V D040331081050S
C405SBL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C405SBR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C406D nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C406SBL 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C406SBR 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C406X nsp C,CERAMIC 1000PF-K/50V D011102777160S
C407D nsp C,CERAMIC 1000PF-K/50V D011102777160S
C407SBL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C407SBR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C407X 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C408D 00D 963 0338 402 C,ELECT 330UF-M/6.3V D040331081050S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
