Denon AVR-1708 Service Manual

242
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 EUT model
C408SBL 00D 963 0234 506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C408SBR 00D 963 0234 506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C409D nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C409SBL 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C409SBR 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C410D 00D 963 0338 402 C,ELECT 330UF-M/6.3V D040331081050S
C410SBL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C410SBR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C411D nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C411SBL 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C411SBR 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C412D nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C412SBL nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C412SBR nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C413D 00D 963 0024 907 C,ELECT 1000UF-M/6.3V D040102081060S
C413SBL 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C413SBR 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C443 nsp C,CERAMIC 1000PF-K/50V D011102777160S
OTHERS PARTS GROUP
CLAMP401 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN203 nsp CN,WIRE 160MM/3P L000161030060S
CN401A nsp CN,WIRE 5P L000191050030S
CN405 nsp CN,WIRE 5P L000321050020S
CN705 nsp CN,WIRE 150MM/3P L000151030010S
CN904 nsp CN,WIRE 6P L000141060030S
CP102 nsp CN.WAFER 2.5MM 5267-03A 3P L102526700300S
CP201 nsp CN.WAFER 10P L101220100000S
CP402 nsp CN.WAFER 3P L102526700300S
L401SBL nsp COIL INDUCTOR 0.5UH D330R50000000S
L401SBR nsp COIL INDUCTOR 0.5UH D330R50000000S
TP401,402 nsp CN.WAFER 3P ANGLE L101530150310S
00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
