Denon AVR-1708 Service Manual

336
AVR-1708/1508/688/588/488 AVC-1508
51A nsp CPU P.W.B. ASSY AVR1708E3
7025HK0705015
1*
51A nsp CPU P.W.B. ASSY AVR688E3
7025HK0705025
1*
51A nsp CPU P.W.B. ASSY AVR1708E2
7025HK0705035
1*
51A nsp CPU P.W.B. ASSY AVR1508E3
7025HK0704025
1*
51A nsp CPU P.W.B. ASSY AVR588E3
7025HK0704035
1*
51A nsp CPU P.W.B. ASSY AVR1508E2
7025HK0704045
1*
51A nsp CPU P.W.B. ASSY AVR1508EUT
7025HK0704055
1*
51A nsp CPU P.W.B. ASSY AVC1508JP
7025HK0704065
1*
51A nsp CPU P.W.B. ASSY AVR488E3
7025HK0704015
1*
51 CPU ASSY 1
52A nsp INPUT P.W.B. ASSY AVR1708E3
7025HK0705012
1*
52A nsp INPUT P.W.B. ASSY AVR688E3
7025HK0705022
1*
52A nsp INPUT P.W.B. ASSY AVR1708E2
7025HK0705032
1*
52A nsp INPUT P.W.B. ASSY AVR1508E3
7025HK0704022
1*
52A nsp INPUT P.W.B. ASSY AVR588E3
7025HK0704032
1*
52A nsp INPUT P.W.B. ASSY AVR1508E2
7025HK0704042
1*
52A nsp INPUT P.W.B. ASSY AVR1508EUT
7025HK0704052
1*
52A nsp INPUT P.W.B. ASSY AVC1508JP
7025HK0704062
1*
52A nsp INPUT P.W.B. ASSY AVR488E3
7025HK0704012
1*
52 INPUT ASSY
53A nsp VIDEO P.W.B. ASSY AVR1708E3
7025HK0705017
1*
53A nsp VIDEO P.W.B. ASSY AVR688E3
7025HK0705027
1*
53A nsp VIDEO P.W.B. ASSY AVR1708E2
7025HK0705037
1*
53A nsp VIDEO P.W.B. ASSY AVR1508E3
7025HK0704028
1*
53A nsp VIDEO P.W.B. ASSY AVR588E3
7025HK0704038
1*
53A nsp VIDEO P.W.B. ASSY AVR1508E2
7025HK0704048
1*
53A nsp VIDEO P.W.B. ASSY AVR1508EUT
7025HK0704058
1*
53A nsp VIDEO P.W.B. ASSY AVR488E3
7025HK0704018
1*
53 VIDEO ASSY
54A 00D9630368700 HDMI P.W.B. ASSY
AVR1708E3/AVR688E3/
AVR1508E3/AVR588E3/
AVR488E3
7025HK0705016
1*
54 HDMI ASSY
54B 00D9630368807 HDMI P.W.B. ASSY
AVR1708E2/
AVR1508E2/
AVR1508EUT/
AVC1508JP
7025HK0705036
1*
54 HDMI ASSY
33A nsp 2CH P.W.B. ASSY AVR1708E3
7025HK0705014
1*
33A nsp 2CH P.W.B. ASSY AVR688E3
7025HK0705024
1*
33A nsp 2CH P.W.B. ASSY AVR1708E2
7025HK0705034
1*
33A nsp 2CH P.W.B. ASSY AVR1508E3
7025HK0704024
1*
33A nsp 2CH P.W.B. ASSY AVR588E3
7025HK0704034
1*
33A nsp 2CH P.W.B. ASSY AVR1508E2
7025HK0704044
1*
33A nsp 2CH P.W.B. ASSY AVR1508EUT
7025HK0704054
1*
33A nsp 2CH P.W.B. ASSY AVC1508JP
7025HK0704064
1*
33 2CH ASSY
33B nsp 2CH POWER P.W.B ASSY AVR488E3
7025HK070401A
1*
33 SUB ASSY
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
