Denon AVR-1708 Service Manual

337
AVR-1708/1508/688/588/488 AVC-1508
58A nsp D-VIDEO P.W.B. ASSY AVC1508JP
7025HK0704069
1*
58 VIDEO ASSY
59 D-VIDEO1 ASSY
60 D-VIDEO2 ASSY
1 00D9630358509 WINDOW AVR1708E3
5077212382000S
1*
1 00D9630358602 WINDOW AVR688E3
5077211922200S
1*
1 00D9630358705 WINDOW AVR1708E2
5077212382010S
1*
1 00D9630358808 WINDOW AVR1508E3
5077212382030S
1*
1 00D9630358901 WINDOW AVR588E3
5077211922220S
1*
1 00D9630359007 WINDOW AVR1508E2
5077212382010S
1*
1 00D9630359100 WINDOW AVR1508EUT
5077212382040S
1*
1 00D9630359203 WINDOW AVC1508JP
5077212382050S
1*
1 00D9630359306 WINDOW AVR488E3
5077211922210S
1*
2 00D9630361704 KNOB FUNCTION
AVR1708E3/BKE2/
AVR1508E3
5087211461000S
1*
2 00D9630138301 KNOB FUNCTION AVR688E3/588E3/488E3
5087210961000S
1*
2 00D9630361807 KNOB FUNCTION
AVR1708SRE2/
AVR1508SRE2
5087211461100S
1*
2 00D9630361900 KNOB FUNCTION AVR1508EUT
5087211461110S
1*
2 00D9630362006 KNOB FUNCTION AVC1508JP
5088211508020SZ
1*
3 00D9630362109 BADGE Black
5630210028300S
1*
3 00D9630051527 BADGE Silver
5630210028200S
1*
3 00D9630362202 BADGE Premium Silver
5630210028400S
1*
4 00D9630359409 PANEL FRONT AVR1708E3
3067213241000S
1*
4 00D9630359502 PANEL FRONT AVR688E3
3067213271010S
1*
4 00D9630359605 PANEL FRONT AVR1708BKE2
3067213241400S
1*
4 00D9630359708 PANEL FRONT AVR1708SRE2
3067213241100S
1*
4 00D9630359801 PANEL FRONT AVR1508E3
3067213241200S
1*
4 00D9630359904 PANEL FRONT AVR588E3
3067213271110S
1*
4 00D9630360000 PANEL FRONT AVR1508E2
3067213241110S
1*
4 00D9630360103 PANEL FRONT AVR1508EUT
3067213241300S
1*
4 00D9630360206 PANEL FRONT AVC1508JP
3067213258030S
1*
4 00D9630360309 PANEL FRONT AVR488E3
3067213271100S
1*
5 00D9630137807 LENS STANDBY
3710210503000S
1
6 00D9630184009 BUTTON POWER Black
5097212358000SZ
1
6 00D9630139805 BUTTON POWER Silver
5097212358100SZ
1
6 00D9630230005 BUTTON POWER Premium Silver
5097212358300SZ
1
7 00D9630184106 BUTTON STANDBY Black
5097212368000SZ
1
7 00D9630140108 BUTTON STANDBY Silver
5097212368010SZ
1
7 00D9630221904 BUTTON STANDBY Premium Silver
5097212368030SZ
1
8 00D9630361601 FRAME FRONT AVC1508JP
3217211521200S
1*
8 00D9630362305 BUTTON 2KEY Black
5097213351000S
1*
8 00D9630362408 BUTTON 2KEY Silver
5097213351100S
1*
8 00D9630362501 BUTTON 2KEY
Premium Silver
(except for AVC1508JP)
5097213351110S
1*
12 00D9630190200 COVER RCA Black
4317211701000S
1
12 00D9630190307 Silver
4317211701100S
1
12 00D9630239705
Premium Silver
(except for AVC1508JP)
4317212231110S
1
13 00D9600191417 LENS LED
3710210043001S
2
15 00D9630362604 KNOB VOLUME
AVR1708E3/BKE2/
AVR1508E3
5087211471000S
1*
15 00D9630138806 KNOB VOLUME
AVR688E3/AVR588E3/
AVR488E3
5087210981000S
1*
15 00D9630362707 KNOB VOLUME
AVR1708SRE2/
AVR1508SRE2
5087211471100S
1*
15 00D9630362800 KNOB VOLUME AVR1708EUT
5087211471110S
1*
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
