Denon AVR-1708 Service Manual

338
AVR-1708/1508/688/588/488 AVC-1508
15 00D9630362903 KNOB VOLUME AVC1508JP
5088211498020SZ
1*
16 00D9630363009 KNOB SELECT
AVR1708E3/BKE2/
AVR1508E3
5087211481000S
1*
16 00D9630344302 KNOB SELECT
AVR688E3/AVR588E3/
AVR488E3
5087211281000S
1*
16 00D9630364102 KNOB SELECT
AVR1708SRE2/
AVR1508SRE2
5087211481100S
1*
16 00D9630364205 KNOB SELECT AVR1708EUT
5087211481110S
1*
16 00D9630364308 KNOB SELECT AVC1508JP
5088211518020SZ
1*
17 00D9630364401 BUTTON 4KEY
AVR1708E3/BKE2/
AVR1508E3
5097213341000S
1*
17 00D9630139407 BUTTON 4KEY
AVR688E3/AVR588E3/
AVR488E3
5097212341000S
1*
17 00D9630364504 BUTTON 4KEY
AVR1708SRE2/
AVR1508SRE2
5097213341100S
1*
17 00D9630364607 BUTTON 4KEY AVR1708EUT
5097213341110S
1*
18 00D9630364700 BUTTON 3KEY
AVR1708E3/BKE2/
AVR1508E3
5097213331000S
2*
18 00D9630139106 BUTTON 3KEY
AVR688E3/AVR588E3/
AVR488E3
5097212331000S
2*
18 00D9630364803 BUTTON 3KEY
AVR1708SRE2/
AVR1508SRE2
5097213331100S
2*
18 00D9630364906 BUTTON 3KEY AVR1708EUT
5097213331110S
2*
19 00D9630365002 BUTTON WIN 3KEY
AVR1708E3/BKE2/
AVR1508E3
5097213371000S
2*
19 00D9630365105 BUTTON WIN 3KEY
AVR688E3/AVR588E3/
AVR488E3
5090213391000S
2*
19 00D9630365208 BUTTON WIN 3KEY
AVR1708SRE2/
AVR1508SRE2
5097213371100S
2*
19 00D9630365301 BUTTON WIN 3KEY
AVR1708EUT/
AVC1508JP
5097213371110S
2*
20 00D9630365404 BUTTON WIN 6KEY
AVR1708E3/BKE2/
AVR1508E3
5097213361000S
1
20 00D9630365507 BUTTON WIN 6KEY
AVR688E3/AVR588E3/
AVR488E3
5090213381000S
1
20 00D9630365600 BUTTON WIN 6KEY
AVR1708SRE2/
AVR1508SRE2
5097213361100S
1
20 00D9630365703 BUTTON WIN 6KEY
AVR1708EUT/
AVC1508JP
5097213361110S
1
27 nsp BRACKET HEATSINK L
4010213146000S
1*
28 nsp HEAT SINK MAIN except for AVR488E3
2120211138000S
1*
28 nsp HEAT SINK MAIN AVR488E3
2120211148000S
1*
29 nsp BRACKET HEATSINK R
4010213136000S
1*
31 nsp POSISTOR P43T7D330BW16
F320161001020S
1
32 nsp BRACKET PCB
4010210186000S
2
40 00D9630214607 CUSHION FOOT
4050211295000S
4
41 00D9630137904 FOOT
4007210261000S
4
42 nsp CHASSIS MAIN
3200212146000S
1*
43 nsp SUPPORTER PCB
4070001601010S
3
45 nsp BRACKET TRANS
4010210466002S
1
z 46 00D9630367905 POWER TRANS MAIN AVR1708E3/AVR688E3
8200960660240S
1
z 46 00D9630368001 POWER TRANS MAIN AVR1708E2
8200960660250S
1
z 46 00D9630368108 POWER TRANS MAIN
AVR1508E3/
AVR1508EUT/AVR588E3
8200960660260S
1
z 46 00D9630368205 POWER TRANS MAIN AVR1508E2
8200960660270S
1
z 46 00D9630368302 POWER TRANS MAIN AVR1508JP
8200960660290S
1
z 46 00D9630368409 POWER TRANS MAIN AVR488E3
8200960660280S
1
70 00D9630360402 CHASSIS BACK AVR1708E3
3207212156502S
1*
70 00D9630360505 CHASSIS BACK AVR688E3
3207212156512S
1*
70 00D9630360608 CHASSIS BACK AVR1708E2
3207212156600S
1*
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
