Denon AVR-1708 Service Manual

339
AVR-1708/1508/688/588/488 AVC-1508
70 00D9630360701 CHASSIS BACK AVR1508E3
3207212156803S
1*
70 00D9630360804 CHASSIS BACK AVR588E3
3207212156A03S
1*
70 00D9630389909 CHASSIS BACK AVR1508E2
3207212156611S
1*
70 00D9630361003 CHASSIS BACK AVR1508EUT
3207212156700S
1*
70 00D9630361106 CHASSIS BACK AVC1508JP
3207212156401S
1*
70 00D9630361209 CHASSIS BACK AVR488E3
3207212156903S
1*
71 00D9630145608 TUNER PACK
AVR1708E3/AVR688E3/
AVR1508E3/AVR588E3/
AVR488E3
E903014000020S
1*
71 00D9630145705 TUNER PACK
AVR1708E2/
AVR1508E2/
AVR1508EUT
E903014100030S
1*
72 00D9600192403 STOPPER CORD AC except for AVC1508JP
4380210002000S
1
z 73 00D9630292205 AC CORD
AVR1708E3/AVR688E3/
AVR1508E3/AVR588E3/
AVR488E3
L068125100020S
1
z 73 00D9630292409 AC CORD AVR1708E2/AVR1508E2
L068250250040S
1
z 73 00D9630292302 AC CORD AVR1508EUT
L068125110000S
1
74 00D9630158404 AC INLET AVC1508JP
G430040560020S
1
75 nsp LABEL ORIGIN AVR1508EUT
5507003020021S
1
80 00D9630361302 CABINET TOP Black
3000210936000S
1*
80 00D9630361405 CABINET TOP Silver/Premium Silver
3000210936100S
1*
80 00D9630361508 CABINET TOP AVC1508JP
3000210926100S
1*
81 nsp COVER SAFETY E2, EUT model
4310212122010S
1*
82 nsp COVER HOLDER E2, EUT model
4310213701000S
1*
83 nsp CUSHION SIDE
4050211095000S
1*
84 nsp CUSHION PCB except for AVC1508JP
4050211095000S
1*
84 nsp CUSHION PCB AVC1508JP
4050211105000S
1*
85 nsp SUPPORTER BUTTON LOCK
4070000020000S
1*
★ 86
nsp LABEL RATING FUSE CAUTION for only E3 model
5527042410030S
1
87 nsp LABEL(TRANS)
5507051740120S
1
88 00D3420043000 FERRITE CLAMP102010N 1
89 nsp HDMI PWR ASSY
7025HK0705018
1*
90 nsp CLAMP(MTG)
4330000310000S
2
91 nsp SHEET CABINET
AVR688E3/AVR588E3/
AVR488E3
1210210235000S
4*
92 nsp SUPPORTER AVC1508JP
4070211583000S
1*
93 nsp SUPPORTER AVC1508JP
4070000340000S
1*
★ 91
00D9630365806 CABLE,FLAT CARD 1.25MM
N712151344810S
1*
★ 92
00D9630365909 CABLE,FLAT CARD 1.25MM except for AVC1508JP
N712351534810S
1*
96 nsp INSULATION SHEET AVR1508EUT
1240210099000S
1
97 nsp PLATE EARTH AVR1508EUT
4470211366000S
2
98 nsp GASKET EMC A(30*10*T6) AVR1508EUT
4400210179000S
2
99 nsp GASKET EMC B(30*5*T2) AVR1508EUT
4400210189000S
2
T1 00D9630044107 TR PNP 2SB1560-Y Q102 FL/FR/C/SL/SR
J5011560Y0000S
5*
T2 00D9630280107 TR NPN 2SC3964 Q103 FL/FR/C/SL/SR
J502396400000S
5*
T3 00D9630044204 TR NPN 2SD2390-Y Q101 FL/FR/C/SL/SR
J5032390Y0000S
5
Screws
A nsp SCREW(3X8 B-TYPE ZNY/BH)
AVR1708E3/
AVR1708E2/
AVR1508E2/AVR688E3
B020030081B10S
66
A nsp SCREW(3X8 B-TYPE ZNY/BH)
AVR1508E3/
AVR1508EUT/
AVR588E3/AVR488E3
63
A nsp SCREW(3X8 B-TYPE ZNY/BH) AVC1508JP 73
B nsp SCREW(3X8 BK WASHER PI12) Black
1500001456020S
5
Ref. No. Part No. Part Name Remarks Q'ty New
g
g
g

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
