Denon AVR-1708 Service Manual

340
AVR-1708/1508/688/588/488 AVC-1508
B nsp SCREW(3X8 BK WASHER NI12) Silver / Premium Silver
1500001456030S
5
C nsp SCREW(3X15 B-TYPE ZNY/BH)
B020030151B10S
2
Dnsp
SCREW(3X10 B-TYPE(DOT) BK/
BH)
AVR1708E3/AVR688E3/
AVC1508JP
B020030103B11S
36
Dnsp
SCREW(3X10 B-TYPE(DOT) BK/
BH)
AVR1708E2/
AVR1508E3/
AVR1508E2/
AVR1508EUT/AVR588E3
35
Dnsp
SCREW(3X10 B-TYPE(DOT) BK/
BH)
AVR488E3 34
Ensp
SCREW(3X14 P+S-WASHER
ZNY/HH)
AVR1708E3/AVR688E3/
AVR1508E3/AVR588E3
B018230141H11S
25
Ensp
SCREW(3X14 P+S-WASHER
ZNY/HH)
AVR1708E2/
AVR1508E2/
AVR1508EUT/
AVC1508JP
24
Ensp
SCREW(3X14 P+S-WASHER
ZNY/HH)
AVR488E3 19
F nsp SCREW(3X17 B-TYPE ZNY/BH)
B020030171B10S
3
G 00D9630048307
SCREW(4X8 B-TYPE(DOT) BK/
BH)
Black
1500040083B10S
6
G 00D9639004012
SCREW(4X8 B-TYPE(DOT) NI/
BH)
Silver / Premium Silver
1500040084B10S
6
Hnsp
SCREW(4X10 P+S-WASHER
ZNY/BH)
B028940101B10S
4
Insp
SCREW(3X8 ZnY WASHER
PI12)
1500001456010S
3
J nsp SCREW(4X6 S-TYPE ZNY/BH)
B020740061B10S
6
L nsp SCREW(3X10 B-TYPE BK/FH) AVC1508JP
B020030103F10S
2
P nsp SCREW(3X8 S-TYPE BK/BH)
B020030063B10S
2
Q nsp SCREW(3X8 S-TYPE BK/BH)
B020930083B10S
5
R nsp SCREW(2*8 B-TYPE BLACK/BH) AVC1508JP
B020020081B10S
8
Snsp
SCREW(3X8 B-TYPE ZNW/
BH(2EA)
AVR1508EUT
B020030081B10S
2
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
