46
AVR-1709/1609/1519/1509/689/589, AVC-1509
15 XIN XIN I - - I I Clock (Input)
16 VCC VCC - - - - - +5V
17 P85/NMI NMI
I- - - --
18 P84/INT2 FLAG0 I - Z O/L O/L DSP (IC801: ADSP21367) Control
19 P83/INT1 POWER DOWN I - Z I I Power Down Detect (Det="L")
20 P82/INT0 PROTECTION
I - Z I I Abnorma (DC/ASO) Detect (Det="L")
21 P81 SIRIUS P/E O C Z O/L O/L SIRIUS Ready Control
22 P80 HDMI_RST O C Z O/L O/L HDMI I-O Selector (IC01: Sil9185) Control
23 P77 FLD_RESET O C Z O/L O/L FL Driver (IC302:LC87F6D64A) Control
24 P76 FLD_CE O C Z O/L O/L FL Driver (IC302:LC87F6D64A) Control
25 P75 FLD/2092_CLK O C Z O/L O/L FL Driver (IC302:LC87F6D64A)
&LED Driver (IC301: BU2092) Control
26 P74 FLD/2092_DATA O C Z O/L O/L FL Driver (IC302:LC87F6D64A)
&LED Driver (IC301: BU2092) Control
27 P73/CTS2 2092-LCK O C Z O/L O/L LED Driver (IC301: BU2092) Control
28 P72/CLK2 2092-OE O C Z O/L O/L LED Driver (IC301: BU2092) Control
29 P71/RXD2 SIRIUS Rx I - Z I O/L SIRIUS Ready Control
30 P70/TXD2 SIRIUS Tx O N Z O/L O/L SIRIUS Ready Control
31 P67/TXD1 TXD MO232I O C Z O/L O/L ROM Update Control
32 P66/RXD1 RXD MI232O I - Z I O/L ROM Update Control
33 P65/CLK1 LIMIT DET I - Z I I Current Limit Detection (Det="L")
34 P64/CTS1 LIMIT O C Z O/L O/L Current Limit Control
35 P63/TXD0 TXD_iPod O C Z O/L O/L iPod Dock Control
36 P62/RXD0 RXD_iPod I - Z I O/L iPod Dock Control
37 P61/CLK0 DYNAMIC_G_LED O C Z O/L O/L DYNAMIC VOL LED Control
38 P60/CTS0 H/P DET I - Z I I HP Jack Insert Detection
39 P57 TUNED
I - Z I I FM/AM Tuned Detection (Det="L")
40 P56 STEREO
I - Z I I FM STEREO Detection (Det="L")
41 P55/EPM FLASH EPM
I - Z I I ROM Update Control
42 P54 VOL UP I - Z O/L O/L MASTER VOLUME Operate Signal Detection
43 P53 VOL DOWN I - Z O/L O/L MASTER VOLUME Operate Signal Detection
44 P52 SEL UP I - Z O/L O/L SELECTOR Knob Operate Signal Detection
45 P51 SEL DOWN I - Z O/L O/L SELECTOR Knob Operate Signal Detection
46 P50/CE FLASH CE I - Z I I ROM Update Control
47 P47 PLL/RDS DIN O C Z O/L O/L TUNER PLL (LC72131)
/RDS (IC805: LC72722) Control
48 P46 PLL/RDS CLK O C Z O/L O/L TUNER PLL (LC72131)
/RDS (IC805: LC72722) Control
49 P45 PLL STB O C Z O/L O/L TUNER PLL (LC72131) Control
50 P44 PLL_DOUT I - Z O/L O/L TUNER PLL (LC72131) Control
51 P43 RDS RESET O C Z O/L O/L RDS (IC805: LC72722) Control
52 P42 RDS CE O C Z O/L O/L RDS (IC805: LC72722) Control
53 P41 RDS DOUT I - Z O/L O/L RDS (IC805: LC72722) Control
54 P40 89057 INT I - Z O/L O/L DIR (IC807: LC89057) Control
55 P37 89057 RESET O C Z O/L O/L DIR (IC807: LC89057) Control
56 P36 89057 CE O C Z O/L O/L DIR (IC807: LC89057) Control
57 P35 89057 SDIN I C Z O/L O/L DIR (IC807: LC89057) Control
58 P34 89057 EMPHA I - Z O/L O/L DIR (IC807: LC89057) Control
59 P33 V-CODEC RESET
/V-MUTE
O C Z O/L O/L VIDEO CODEC (IC1019: ADV7172
&IC1018: ADV7180) Control
60 P32 SHARC_CE O C Z O/L O/L DSP (IC801: ADSP-21367) Control
61 P31 V-CODEC_SDA O C Z O/L O/L VIDEO CODEC (IC1019: ADV7172
&IC1018: ADV7180) Control
62 VCC VCC - - - - - +5V
63 P30 V-CODEC_SCL O C Z O/L O/L VIDEO CODEC (IC1019: ADV7172
&IC1018: ADV7180) Control
64 VSS VSS - - - - - GND
65 P27 SHARC_RESET O C Z O/L O/L DSP (IC801: ADSP-21367) Control
66 P26 EEPROM RESET O C Z O/L O/L Flash Memory (IC803: EN29LV160AB-70TI) Control
67 P25 DSP POWER O - Z O/L O/L Digital Power Supply Control
Pin Port Name I/O Type Res Stby Stop Description
