Denon AVR-1709 Service Manual

87
AVR-1709/1609/1519/1509/689/589, AVC-1509
C224L 00D9630234205 C,ELECT 10UF-M/50V AVR1709 D040100087070S
C224R 00D9630234205 C,ELECT 10UF-M/50V AVR1709 D040100087070S
C231 00D9630244606 C,ELECT 0.1UF-M/50V (Pb Free) AVR1709, 689 D040R10087080S
C232 nsp C,CERAMIC 0.01UF-K/50V AVR1709, 689 D010103777160S
C233 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) AVR1709, 689 D040010087150S
C234 nsp C,CERAMIC 100PF-J/50V AVR1709, 689 D010101167160S
C235,236 00D9609008653 C,FILM 0.012UF-J/100V AVR1709, 689 D02012306C060S
C237 00D9639005862 C,ELECT 47UF-M/16V AVR1709, 689 D040470083080S
C238-241 00D9630234205 C,ELECT 10UF-M/50V AVC1509 D040100087070S
OTHERS PARTS GROUP
CLAMP101 nsp CLAMP WIRE(SOLDER)
4330000120000S
CN101 nsp CN,WIRE 10P L000111100070S
CN103 nsp CN,WIRE 7P L000121070061S
CN201 nsp CN,WIRE 6P AVR1709, 689 L000700060111S
CN511 nsp CN,WIRE 9P L000600090021S
CN704 nsp CN.WAFER 15P L101100041510S
CP103 nsp CN.WAFER 3P AVR1709, 689 L102526700300S
CP104 nsp CN.WAFER 3CKT L108353280360S
CP105 nsp CN.WAFER 7P L101100040710S
CP106 nsp CN.WAFER 5P L101100040510S
CP107 nsp CN.WAFER 3P L102526700300S
CP108 nsp CN.WAFER 18P L101100041810S
CP109 nsp CN.WAFER 5P L101100040510S
CP541 nsp CN.WAFER 3P L101200100310S
GND101 nsp TERMINAL EARTH 3790040886000S
JACK221 90M-YT004640R MODULE JSR1165-C AVR1709 G601207AE020YS
JACK222 00D9630146005 TER,RCA 1PIN G600107A0000YS
JACK223 90M-YT004640R MODULE JSR1165-C AVC1509 G601207AE020YS
JACK231,232 00D9630244703 JACK,D3.5 EARPHONE AVR1709, 689 G40130802000YS
L101C 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L101FL 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L101FR 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L101SL 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L101SR 00D9630049005 COIL INDUCTOR 0.5UH D330R50000000S
L231 nsp BEAD,COIL 3580 AVR1709, 689 7610010030000S
RLY541 00D9630218506 RELAY BC3-24 24V 2A G680240202040S
TP101-105 nsp CN.WAFER 3P L101530140310S
Ref. No. Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-1709 Specifications

General

Number of Channels	7.1
HDMI Inputs	3
HDMI Outputs	1
HDMI Version	1.3a
Component Video Inputs	2
Component Video Outputs	1
Digital Audio Inputs	2 Optical, 2 Coaxial
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Presets	56
HDMI Switching	Yes
Tuner Type	AM/FM
Preset Stations	56
Auto Calibration	Yes (Audyssey MultEQ)
Power Consumption	460 W
Standby Power Consumption	0.3 W
Power Output	80 W per channel (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
HDMI Features	Deep Color, x.v.Color
Dolby Formats	Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby TrueHD
DTS Formats	DTS, DTS-ES, DTS 96/24, DTS Neo:6, DTS-HD Master Audio
Audio Decoders	Dolby Digital, DTS
Amplifier Output Details	80 watts per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Remote Control	Yes
Dimensions	434 x 171 x 377 mm
Weight	21.6 lbs (9.8 kg)
