Denon AVR-1709 Service Manual

94
AVR-1709/1609/1519/1509/689/589, AVC-1509
OTHERS PARTS GROUP
BD701-703 nsp COIL,BEAD MB-160808 AVR1509E2
D340160800060S
CN306 nsp CN,WIRE 3P AVR1509E2 L000481030061S
CN514 nsp CN,WIRE 15P AVR1509E2 L000181150011S
CN515 nsp CN,WIRE 4P AVR1509E2 L000321040040S
CN702 nsp CN.HOUSING 12P AVR1509E2 L120912120010S
CN703 nsp CN.WAFER 8P AVR1509E2 L101100030810S
CN704 nsp CN.WAFER 19P AVR1509E2 L101100031910S
CN705 nsp CN,WIRE 3P AVAR1709, 689 L000151030011S
CN707 nsp CN.WAFER 15P AVR1509E2 L101100031510S
CN708 nsp CN,WIRE 15P AVR1509E2 L000161150050S
CP708 nsp CN.WAFER 11P AVR1509E2 L101100041110S
JACK701 90M-YT004640R MODULE JSR1165-C AVR1509E2 G601207AE020YS
JACK701 00D9630132103 TER,RCA 4PIN AVAR1709, 689 G602405B0400YS
JACK702 00D9630388203 TER,RCA 4PIN AVR1509E2 G602405B5500YS
JACK703 00D9630132103 TER,RCA 4PIN AVR1509E2 G602405B0400YS
JACK704,705 00D9630132307 TER,RCA 6PIN AVR1509E2 G603603B05000S
Ref. No. Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-1709 Specifications

General

Number of Channels	7.1
HDMI Inputs	3
HDMI Outputs	1
HDMI Version	1.3a
Component Video Inputs	2
Component Video Outputs	1
Digital Audio Inputs	2 Optical, 2 Coaxial
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Presets	56
HDMI Switching	Yes
Tuner Type	AM/FM
Preset Stations	56
Auto Calibration	Yes (Audyssey MultEQ)
Power Consumption	460 W
Standby Power Consumption	0.3 W
Power Output	80 W per channel (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
HDMI Features	Deep Color, x.v.Color
Dolby Formats	Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby TrueHD
DTS Formats	DTS, DTS-ES, DTS 96/24, DTS Neo:6, DTS-HD Master Audio
Audio Decoders	Dolby Digital, DTS
Amplifier Output Details	80 watts per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Remote Control	Yes
Dimensions	434 x 171 x 377 mm
Weight	21.6 lbs (9.8 kg)
