Denon AVR-1709 Service Manual

96
AVR-1709/1609/1519/1509/689/589, AVC-1509
C519 00D9630324704 C,ELECT 4700UF-M/16V AVR1709, 689 D040472083200S
C520 00D9630021104 C,ELECT 6800UF-M/16V AVR1709, 689 D040682083000S
C521-523 00D9630021900 C,FILM 0.047UF-J/100V AVR1709, 689 D02047306C060S
C524,525 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C526,527 00D9609010133 C,ELECT 220UF-M/35V D040221085060S
C528 00D9630324908 C,ELECT 4700UF-M/35V D040472085020S
C529 00D9630224707 C,ELECT 2200UF-M/35V D040222085020S
C530-532 00D9630021900 C,FILM 0.047UF-J/100V D02047306C060S
C534,535 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
OTHERS PARTS GROUP
BKT501 nsp BRACKET 0.8t/SCREW AVR589E3
4010210196100S
BKT502 nsp BRACKET 0.8t/SCREW AVR1509E1C 4010210196100S
CLAMP101,102
nsp CLAMP WIRE(SOLDER) 4330000120000S
CLAMP104 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN505 nsp CN.WAFER 7P L101100030710S
CN506 nsp CN.WAFER 14P L101100031410S
CN704 nsp CN.WAFER 15P L101100031510S
CN708 nsp CN.WAFER 11P L101100031110S
CP501 nsp CN.WAFER 2CKT,YEL L108353280290S
CP503 nsp CN.WAFER 2CKT,RED L108353280280S
CP504 nsp CN.WAFER ST2P L108202000220S
CP505 nsp CN.WAFER 7P L101100040710S
CP506 nsp CN.WAFER 14P L101100041410S
CP511 nsp CN.WAFER 9P L101200100910S
CP512 nsp CN.WAFER 4P ANGLE AVR1709, 689 L102526800400S
CP513 nsp CN.WAFER 3P ANGLE L102526803010S
CP514 nsp CN.WAFER 15P L101200101510S
CP704 nsp CN.WAFER 15P L101100041510S
CP708 nsp CN.WAFER 11P L101100041110S
z F501 00D9630104801 FUSE T3.15A /250V E2, E1C, EA N751223151110S
z F501 00D9630104908 FUSE T6.3A /250V E3, JP N751226301110S
F501A nsp HOLDER,FUSE CLIP G645000050010S
F501B nsp HOLDER,FUSE CLIP G645000050010S
z F503 00D9630104704 FUSE T2.5A /250V AVR1709E2, 1509E2/E1C,
1519E1C, 589EA,
N751222501110S
z F503 00D9630236106 FUSE T8A /250V AVR1709E3, 1609E3,
689E3, 589E3
N751228001110S
z F503 00D9600194906 FUSE 125V AVC1509 G650802121070S
F503A nsp HOLDER,FUSE CLIP AVR1509E2/E1C, 1519E1C,
589EA/E3
G645000050010S
F503B nsp HOLDER,FUSE CLIP AVR1509E2/
E1C,1519E1C,589EA/E3
G645000050010S
GND501 nsp TERMINAL EARTH 3790040886000S
z JACK501 963641000810S SOCKET,POWER RECEPTA AVR1709E2, 1509E2,
589EA
G435302D00600S
z JACK501 00D9600181508 SOCKET,POWER RECEPTA E3, JP G435204004010S
RLY501 963682000640S RELAY HL3-1A-6SH G680060102020S
Ref. No. Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-1709 Specifications

General

Number of Channels	7.1
HDMI Inputs	3
HDMI Outputs	1
HDMI Version	1.3a
Component Video Inputs	2
Component Video Outputs	1
Digital Audio Inputs	2 Optical, 2 Coaxial
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	100 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Presets	56
HDMI Switching	Yes
Tuner Type	AM/FM
Preset Stations	56
Auto Calibration	Yes (Audyssey MultEQ)
Power Consumption	460 W
Standby Power Consumption	0.3 W
Power Output	80 W per channel (8 ohms, 20 Hz - 20 kHz, THD 0.08%)
HDMI Features	Deep Color, x.v.Color
Dolby Formats	Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby TrueHD
DTS Formats	DTS, DTS-ES, DTS 96/24, DTS Neo:6, DTS-HD Master Audio
Audio Decoders	Dolby Digital, DTS
Amplifier Output Details	80 watts per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Video Inputs/Outputs	Composite
Audio Inputs/Outputs	Digital Optical
Remote Control	Yes
Dimensions	434 x 171 x 377 mm
Weight	21.6 lbs (9.8 kg)
