SURROUND
Before playing with the surround function
• Before playing with the surround function, be sure to use the test tones to adjust the playback level from the
different speakers. This adjustment can be performed with the system setup (see page 11) or from the remote
control unit, as described below.
• Adjusting with the remote control unit using the test tones is only possible in the “Auto” mode and only
effective in the DOLBY/DTS SURROUND modes. The adjusted levels for the different modes are automatically
stored in the memory.
2
Press the TEST TONE button.
Test tones are output from
the different speakers. Use
the channel volume adjust
buttons to adjust so that
the volume of the test
tones is the same for all
the speakers.
4
After completing the
adjustment, press the
TEST TONE button again.
1
Set the DOLBY/DTS SURROUND (Dolby Pro
Logic
II or Dolby Digital or DTS) modes.
(Main unit) (Remote control unit)
• After adjusting using the test tones, adjust the channel levels either according to the playback sources or to
suit your tastes, as (described) below.
1
Select the speaker whose
level you want to adjust.
2
The channel switches as shown below each
time the button is pressed.
Adjust the level of the
selected speaker.
(Remote control unit)
NOTE:
• Please make sure the “AUDIO” position of
the slide switch on the remote control unit.
Default setting of channel level is 0 dB.
The level of the selected speaker can be
adjusted within the range of +12 to –12 dB
using the cursor buttons.
SW channel level can be turned off by
decreasing one step from -12 dB.
OFF ´ -12 dB ´ 12 dB
(Remote control unit)
(Remote control unit)
3
(Remote control unit)
ENGLISH
NOTE:
• Please make sure the “AUDIO” position of
the slide switch on the remote control unit.
