Denon AVR-1907 Operating Instructions

Advanced Setup – Part 1 Advanced Setup – Part 1
47
ENGLISH
ENGLISH
The AVR-1907 is equipped with an intuitive and easy-to-understand on screen display, and is equipped with an alphanumeric front panel display
that can also be used to check and adjust settings. We recommend that you use the on screen display when you make system adjustments.
Some representative front display and on screen display examples are shown below.
About the on screen display and front display
[ On screen display ]
Top menu
Main menu
[ Front display ]
A
u t o S e t u p
Top menu
Screen title
No.
Sub-menu title
S
p e a k e r S e t u p
To select a menu, press
DD
or
HH
.
D
i g i t a l I n
Main menu
Screen title
No.
Sub-menu title
* A u t o S e t u p
S
t a r t <
Press
FF
to execute.
Currently selected line
C
O A X 1 < C D >
Current setting
Currently selected line
Audio Input Setup
Setting the Digital In Assignment
This assigns the different input function for the digital input terminals.
Press
DD HH
to select “Audio Input Setup”, then press
ENTER.
Press
DD HH
to select “Digital In Assign”, then press
ENTER.
Press ENTER.
Press
DD HH
to select the input terminals, then press
FF
GG
to set.
• “TUNER” cannot be selected on the “Digital In Assign” screen.
• It is not possible to make the “Digital In Assignment” settings for
the function assigned at “iPod Assignment”.
3
2
1
CD, AUX, DVD, TV, VCR, V. AUX, CDR:
Assign the different function according to the devices connected
to the AVR-1907’s input terminals.
4
1
2
3

Denon AVR-1907 Specifications

General

Speakers connectivity type	-
Equalizer	Yes
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Receiver type	Surround
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	120 W
Power output per channel (20-20KHz@8 Ohm)	85 W
Wi-Fi	No
