Denon AVR-1910 Service Manual

122
AVR-1910/1620/1610/790/590
PARTS LIST OF EXPLODED VIEW (1610/1620/590 model)
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model EA : Australia model
BK : (Black model SP : (Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
50 nsp PCB MAIN ASSY 1610BKE3 7025HK0816010 *
50 nsp PCB MAIN ASSY 1610BKE2
7025HK0816050 *
50 nsp PCB MAIN ASSY 1610SPE2
7025HK0816040 *
50 nsp PCB MAIN ASSY 1610SPE1C
7025HK0816060 *
50 nsp PCB MAIN ASSY 1620SPE1C
7025HK0816020 *
50 nsp PCB MAIN ASSY 590BKE3
7025HK0816080 *
50 nsp PCB MAIN ASSY 590BKEA
7025HK0816030 *
11A nsp PCB FRONT ASSY 1610BKE3
7025HK0816011 *
11A nsp PCB FRONT ASSY 1610BKE2
7025HK0816051 *
11A nsp PCB FRONT ASSY 1610SPE2
7025HK0816041 *
11A nsp PCB FRONT ASSY 1610SPE1C
7025HK0816061 *
11A nsp PCB FRONT ASSY 1620SPE1C
7025HK0816021 *
11A nsp PCB FRONT ASSY 590BKE3
7025HK0816081 *
11A nsp PCB FRONT ASSY 590BKEA
7025HK0816031 *
z 9 - P/S UNIT *
10 - FUNC UNIT *
11 - FRONT UNIT *
13 - ENCODER UNIT *
14 - H/P UNIT *
21 - V.AUX UNIT *
22 - MIC UNIT *
27 - CNT UNIT *
29 - CABLE GUIDE UNIT *
61 - ENCODER CNT UNIT *
78 - SW UNIT *
79 - SW CNT UNIT *
51 nsp PCB INPUT ASSY 1610BKE3
7025HK0816012 *
51 nsp PCB INPUT ASSY 1610BKE2
7025HK0816052 *
51 nsp PCB INPUT ASSY 1610SPE2
7025HK0816042 *
51 nsp PCB INPUT ASSY 1610SPE1C
7025HK0816062 *
51 nsp PCB INPUT ASSY 1620SPE1C
7025HK0816022 *
51 nsp PCB INPUT ASSY 590BKE3
7025HK0816082 *
51 nsp PCB INPUT ASSY 590BKEA
7025HK0816032 *
57A nsp PCB POWER ASSY 1610BKE3
7025HK0816013 *
57A nsp PCB POWER ASSY 1610BKE2
7025HK0816053 *
57A nsp PCB POWER ASSY 1610SPE2
7025HK0816043 *
57A nsp PCB POWER ASSY 1610SPE1C
7025HK0816063 *
57A nsp PCB POWER ASSY 1620SPE1C
7025HK0816023 *
57A nsp PCB POWER ASSY 590BKE3
7025HK0816083 *
57A nsp PCB POWER ASSY 590BKEA
7025HK0816033 *
26 - 16GUIDE_L UNIT *
56 - SUPPLY UNIT *
z 57 - POWER UNIT *
63 - 16SPK UNIT *
71 - CNT1 UNIT *
55 963189003570D PCB 16HDMI ASSY E3
7025HK0816015 *
55 963189004150D PCB 16HDMI ASSY E2, E1C, EA
7025HK0816045 *
33 nsp PCB 5CHAMP ASSY 1610BKE3
7025HK0816016 *
33 nsp PCB 5CHAMP ASSY 1610BKE2
7025HK0816056 *
33 nsp PCB 5CHAMP ASSY 1610SPE2
7025HK0816046 *

Denon AVR-1910 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	125 W
Power output per channel (20-20KHz@8 Ohm)	90 W
Equalizer	Yes
Product color	Black
Audio decoders	DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby TrueHD
Apple docking compatibility	iPod
Optical drive included	No
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.3 W
HDMI in	4
S-Video inputs quantity	1
Component video (YPbPr/YCbCr) in	2

Weight and Dimensions

Depth	171 mm
Width	434 mm
Height	377 mm
Weight	10700 g
