Denon AVR-1911 User Manual

60
ENGLISH
Remote control operation
buttons
Move the cursor
(Up/Down/Left/Right)
Confirm the setting Return to previous menu
Manual Setup
Setting items Setting details
Quick Select Name
(Continued)
Template : The display name can be changed by selecting “Operation”
and “Device Name” from the previously set templates.
1. Use ui to select the name of the Quick Select setting you want to
change, then press ENTER.
2. Use ui to select “Template”, then press ENTER.
3. Use ui to select “Operation”, then press ENTER.
• Watch / Listen to / Play / For
4. Use uio p to select “Device Name”, then press ENTER.
• BD / DVD / TV / Cable TV / Satellite / DVR / VCR / iPod / V.AUX
/ LD / Movie (When “Operation” is selected to “Watch”.)
• CD / TUNER / iPod / MD / TAPE / Music (When “Operation” is
selected to “Listen to”.)
• PC / Game (When “Operation” is selected to “Play”.)
• Father / Mother / Son / Daughter / Brother / Sister / Grandfather /
Grandmother / Me (When “Operation” is selected to “For”.)
Default : The changed“Quick Select Name” is returned to the default
setting.
• Yes : Reset to the defaults.
• No : Do not reset to the defaults.
Zone Rename
Change the display title of
each zone to one you prefer.
• Up to 10 characters can be input.
• For character input, see page 43.
Default : The changed display names are reset to the defaults.
• Yes : Reset to the defaults.
• No : Do not reset to the defaults.
Display
Adjust the display
brightness of this unit.
Bright : Normal display brightness.
Dim : Reduced display brightness.
Dark : Very low display brightness.
OFF : Turns the display off.
Buttons on the main unit can be used for
operations.
Each time DIMMER is pressed, the
setting is changed as shown below.
Bright Dim
DarkOFF
Setting items Setting details
Setup Lock
Protect settings from
inadvertent change.
ON : Turn protection on.
OFF : Turn protection off.
When canceling the setting, set “Setup Lock” to “OFF”.
NOTE
When “Setup Lock” is set to “ON”, the settings listed below can no
longer be changed. Also, “SETUP LOCKED!” is displayed if you attempt
to operate related settings.
· Menu operations · Dynamic Volume™
· RESTORER · Channel Level
· MultEQ
®
· Dynamic EQ
®

Denon AVR-1911 Specifications

General

Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.8 %
HDMI	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	125 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
I/O ports	1 x Component in 1 x Composite Monitor out 1 x USB 1 x Microphone 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Headphone outputs	7
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W

Weight and Dimensions

Weight	10200 g
