Denon AVR-2105 Operating Instructions

ENGLISH
1
Select the items.
The measurement results of each item can be checked here.
A.Set SpConf.Ck
(Remote control unit)
2
Press the ENTER button and display the verification screen.
(Remote control unit)
NOTE:
• When measurements have been made using the measurement microphone, speakers with a built-in
filter such as subwoofers might be set with a value that differs from the physical distance because of
the internal electrical delay.
[Speaker Config. Check] [Delay Time Check] [Channel Level Check]
3
If the check ends, press the ENTER button again.
(Remote control unit)
4
Select from the following three items based on the measurement
results.
• Store : Set with the checked measurement value.
• Retry : Perform the measurement again.
• Cancel : Cancel the checked measurement value.
A.Set <Store
(Remote control unit)
5
When the “Store” is selected, all parameters are stored up and
switch to the SUBWOOFER MODE setting.
(Remote control unit)
24
Check of the measurement results

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
