Denon AVR-2105 Operating Instructions

10
OPERATION
Before operating
2 1 3
2
3
Preparations:
Check that all connections are proper.
2
Turn on the power.
Press the Power ON/STANDBY switch (button).
ON / STANDBY
3
Select the front speakers.
Press the SPEAKER A or B button to turn the speaker on.
AB
SPEAKER
(Main unit) (Remote control unit)
When pressed, the power turns on and the display lights. The
sound is muted for several seconds, after which the unit
operates normally. When pressed again, the power turns off,
the standby mode is set and the display turns off.
(Main unit) (Remote control unit)
• The front speaker A, B setting can be also be changed with
the SPEAKER button on the remote control unit.
1
Press the Power switch (button).
ON OFF
(Main unit)
• ¢ ON
The power turns on and indicator is light.
Set the power switch to this position to turn the power on
and off from the included remote control unit.
• £ OFF
The power turns off and indicator is off.
In this position, the power cannot be turned on and off from
the remote control unit.
39
ENGLISH

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
