Denon AVR-2308 User Manual

0
Getting Started Connections Setup Playback Remote Control Multi-Zone Information Troubleshooting
ENGLISH
Specifications
n
Audio section
• Power amplifier
Rated output:
Front (A, B):
100 W + 100 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
135 W + 135 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center:
100 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
135 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround:
100 W + 100 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
135 W + 135 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround Back:
100 W + 100 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08 % T.H.D.)
135 W + 135 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Dynamic power:
120 W x 2ch (8 Ω/ohms)
170 W x 2ch (4 Ω/ohms)
Output terminals: Front: A or B
16 ~ 16 Ω/ohms
A + B
12 ~ 16 Ω/ohms
Center, Surround, Surround Back:
16 ~ 16 Ω/ohms
• Analog
Input sensitivity / Input impedance:
200 mV / 47 kΩ/kohms
Frequency response:
10 Hz ~ 100 kHz — +1,–3 dB (DIRECT mode)
S/N:
100 dB (IHF-A weighted) (DIRECT mode)
Distortion:
0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
Rated output:
1.2 V
• Phono equalizer (PHONO input — REC OUT)
Input sensitivity:
2.5 mV
RIAA deviation:
±1 dB (20 Hz to 20 kHz)
S/N:
74 dB (A weighting, with 5 mV input)
Rated output:
150 mV
Distortion factor:
0.03 % (1 kHz, 3 V)
n
Video section
• Standard video terminals
Input / output level and impedance:
1 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +0, –3 dB (when video convert set to “OFF”)
• S-Video terminals
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
C (color) signal — 0.3 (PAL) / 0.286 (NTSC) Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 10 MHz — +0, –3 dB (when video convert set to “OFF”)
• Color component video terminal
Input / output level and impedance:
Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
P
B / CB signal — 0.7 Vp-p, 75 Ω/ohms
P
R / CR signal — 0.7 Vp-p, 75 Ω/ohms
Frequency response:
5 Hz ~ 100 MHz — +0, –3 dB (when video convert set to “OFF”)
n
Tuner section [FM] [AM]
(note: µV at 75 Ω/ohms, 0 dBf = 1 x 10
-15
W)
Receiving Range: 87.5 MHz ~ 108.0 MHz 522 kHz ~ 1611 kHz
Usable Sensitivity: 1.0 µV (11.2 dBf) 18 µV
50 dB Quieting Sensitivity: MONO 1.6 µV (15.3 dBf)
STEREO 23 µV (38.5 dBf)
S/N (IHF-A): MONO 77 dB (IHF-A weighted)
STEREO 72 dB (IHF-A weighted)
Total harmonic Distortion (at 1 kHz): MONO 0.15 %
STEREO 0.3 %
n
General
Power supply: AC 230 V, 50 Hz
Power consumption:
450 W
0.3 W (Standby)
Maximum external dimensions:
434 (W) x 171 (H) x 420 (D) mm
Weight: 12.8 kg
n
Remote control unit (RC-1081)
Batteries: R6P/AA Type (two batteries)
Maximum external dimensions:
52 (W) x 243 (H) x 21 (D) mm
Weight: 184 g (including batteries)
z For purposes of improvement, specifications and design are subject to change without notice.

Denon AVR-2308 Specifications

General

Type	AV Receiver
Number of channels	7.1
Total Harmonic Distortion	0.08 %
Input Sensitivity	200 mV
Signal-to-Noise Ratio	100 dB
Tuner Type	AM/FM
HDMI Inputs	2
HDMI Outputs	1
Component video inputs	3
Component video outputs	1
Dolby Digital	Yes
DTS	Yes
Frequency Response	10 Hz - 100 kHz
Video Outputs	composite video x 1, component video x 1
Digital audio inputs	3 x Optical, 2 x Coaxial
Dimensions	434 x 171 x 414 mm
Speaker Impedance	6-16 Ohm
